GRSE18-P2447 | Photoelectric sensors
The SICK GRSE18-P2447 is a through-beam photoelectric sensor featuring a visible red light source, designed for reliable object detection in industrial automation with a sensing range up to 15 meters and robust IP67 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GRSE18-P2447 | Photoelectric sensors
Brand: SICK
SKU: 1064921
Alternatively Known As: Through-beam photoelectric sensor, M18 photoelectric sensor, SICK photoelectric sensor, industrial object sensor
Technical Specifications
- Functional principle: Through-beam photoelectric sensor
- Sensing range max.: 0 m to 15 m
- Type of light: Visible red light, 650 nm wavelength
- Light source: PinPoint LED
- Light spot size at 10 m: Ø 250 mm
- Adjustment: Potentiometer
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: PNP, complementary
- Switching mode: Light/dark switching
- Response time: < 500 µs
- Switching frequency: 1,000 Hz
- Connection type: Male connector M12, 4-pin
- Circuit protection: Types A, B, D
- Protection class: III
- Housing material: Plastic, ABS
- Optics material: Plastic, PMMA
- Enclosure rating: IP67
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 18mm x 74mm x 18mm
- Weight: 0.1 kg
Key Features
- Through-beam photoelectric sensor with visible red light
- Sensing range up to 15 meters
- Cylindrical housing design with M18 x 1 thread diameter
- Potentiometer adjustment for sensitivity
- LED indicators for power and object detection status
- High switching frequency of 1,000 Hz
- IP67 rated enclosure for dust and water protection
- Robust plastic ABS housing and PMMA optics material
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with electrical and safety standards to ensure proper sensor alignment and secure mounting.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Material handling and packaging systems
- Safety and security systems
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable design minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK GRSE18-P2447 Through-beam Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
