GRTB18-P2487 | Photoelectric sensors
The SICK GRTB18-P2487 is a robust photoelectric proximity sensor featuring background suppression, visible blue LED light, and a sensing range up to 150 mm, ideal for precise object detection in industrial automation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GRTB18-P2487 | Photoelectric sensors
Brand: SICK
SKU: 1101819
Alternatively Known As: Photoelectric proximity sensor, Background suppression sensor, Blue light sensor, Industrial object sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: PNP complementary
- Switching mode: Light/dark switching
- Output current max: ≤ 100 mA
- Response time: < 500 µs
- Switching frequency: 1,000 Hz
- Connection type: Male M12, 4-pin connector
- Circuit protection: Types A, B, D
- Protection class: III
- Housing material: Plastic, ABS
- Optics material: Plastic, PMMA
- Enclosure rating: IP67
- Electromagnetic compatibility: EN 60947-5-2
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Dimensions (H x L x W): 18mm x 74mm x 18mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with background suppression
- Visible blue light LED with 445 nm wavelength
- Sensing range from 20 mm to 150 mm, max 300 mm
- Cylindrical housing design with M18 x 1 thread diameter
- Axial optical axis with Ø 7 mm light spot at 100 mm distance
- Potentiometer adjustment for sensitivity
- Green LED power indicator and yellow LED object detection status
- Switching output: PNP complementary with light/dark switching mode
- High switching frequency of 1,000 Hz and response time under 500 µs
- IP67 rated enclosure for dust and water protection
- Operating temperature range from -25 °C to +55 °C
- Supplied with fastening nuts
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Material handling and packaging systems
- Quality control and inspection processes
- Robotics and conveyor systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable IP67 housing minimizes environmental impact by extending product life
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK GRTB18-P2487 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
