GRTE18S-N1317 | Photoelectric sensors
The SICK GRTE18S-N1317 is a reliable photoelectric proximity sensor featuring a visible red PinPoint LED, robust IP67 rated housing, and precise object detection for industrial automation applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GRTE18S-N1317 | Photoelectric sensors
Brand: SICK
SKU: 1058194
Alternatively Known As: Photoelectric proximity sensor, SICK photo sensor, M18 photoelectric sensor, red light proximity sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: NPN, light switching mode
- Output current max: ≤ 100 mA
- Response time: < 1,000 µs
- Switching frequency: 500 Hz
- Protection class: III
- Housing material: Plastic ABS
- Optics material: Plastic PMMA
- Enclosure rating: IP67
- Operating temperature: -25 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Cable: 3-wire, 2 m PVC
- Dimensions (H x L x W): 18mm x 38mm x 18mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with energetic functional principle
- Visible red light with PinPoint LED light source
- Axial optical axis with sensing range from 5 mm to 100 mm
- Potentiometer adjustment with 270° rotation
- LED indicators for power and object presence
- Robust plastic ABS housing with IP67 enclosure rating
- Cable connection with 3-wire, 2 m PVC cable
- High switching frequency of 500 Hz and response time under 1 ms
- Circuit protection and electromagnetic compatibility compliant
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper electrical connections and sensor alignment.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Material handling and packaging systems
- Safety and monitoring in machinery
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable design minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK GRTE18S-N1317 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
