GRTE18S-P2467 | Photoelectric sensors
The SICK GRTE18S-P2467 is a reliable photoelectric proximity sensor featuring a visible red LED light source, robust IP67 rated housing, and precise object detection for industrial automation applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: GRTE18S-P2467 | Photoelectric sensors
Brand: SICK
SKU: 1069122
Alternatively Known As: Photoelectric sensor, Proximity sensor, Red light sensor, Industrial photo sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: 30 mA
- Switching output: PNP, complementary function
- Switching mode: Light/dark switching
- Output current max: ≤ 100 mA
- Response time: < 1000 µs
- Switching frequency: 500 Hz
- Protection class: III
- Housing material: Plastic ABS
- Optics material: Plastic PMMA
- Enclosure rating: IP67
- Connection type: Male connector M12, 4-pin
- Operating temperature: -25°C to +55°C
- Storage temperature: -40°C to +70°C
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 18mm x 38mm x 18mm
- Weight: 0.1 kg
Key Features
- Photoelectric proximity sensor with energetic functional principle
- Visible red light LED with 650 nm wavelength
- Sensing range from 10 mm to 800 mm, max 5 mm to 1000 mm
- Potentiometer adjustment with 270° rotation
- LED indicators for power and object presence
- Robust plastic ABS housing with IP67 enclosure rating
- Fast switching frequency of 500 Hz and response time under 1000 µs
- Male M12 4-pin connector for easy installation
- Operating temperature range from -25°C to +55°C
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper connection and compliance with safety standards.
Applications
- Industrial automation for object detection
- Material handling and packaging systems
- Safety and monitoring in manufacturing processes
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Energy-efficient LED light source reduces power consumption
- Durable design minimizes waste and replacement frequency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific terms.
Available Now
The SICK GRTE18S-P2467 Photoelectric Proximity Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
