Heatshrink Thin Wall Tubing 4.8MM | Flame Retardant | UV Resistant | 10M by Cabac
Cabac Heatshrink Thin Wall 4.8MM Yellow Green 10M Box provides flexible, flame retardant electrical insulation tubing resistant to abrasion, UV, and common solvents, suitable for electrical and industrial applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Heatshrink Thin Wall 4.8MM Yellow Green 10MBox
Brand: Cabac
SKU: XLP5YG-10M
Alternatively Known As: Thin Wall Heat Shrink Tubing, Polyolefin Heat Shrink Sleeve, Electrical Insulation Tubing, Yellow Green Heatshrink
Technical Specifications
- Material: Electron Beam Cross Linked Polyolefin
- Pre-shrink diameter: 4.8mm
- After-shrink diameter: 2.4mm
- Recovered wall thickness: 0.48mm
- Length: 10 meters per box
- Continuous Operating Temperature: -75 to +135°C
- Shrinkage Temperature: > 105°C
- Longitudinal Shrinkage: < 5%
- Tensile Strength: 10.4 MPa
- Breakdown Voltage: 25 kV/mm wall thickness
- Elongation at Break Point: 400%
- Water Absorption: 0.15% max
- Voltage Rating: 600V
- Heat Shock Resistance: 250°C for 4 hours
- UV Stabilised except clear variants
- Dimensions (H x L x W): n/a mm x 10000mm x n/a mm
- Weight: 0.05 kg
Key Features
- Flame retardant tubing made from Electron Beam Cross Linked Polyolefin
- Flexible, impact, abrasion and UV resistant
- Shrinks to approximately 50% of pre-shrink diameter upon heating
- Resistant to common fluids and solvents
- UL certified and compliant with ASTM D2671
- Continuous operating temperature range from -75 to +135 degrees Celsius
Professional Installation Requirements
- Installation should be performed by qualified personnel using appropriate heat guns such as CABAC HG2232 or HG2233 for proper shrinking and insulation.
Applications
- Electrical insulation and protection of conductors
- Colour coding in electrical and associated industries
- Protection against environmental factors such as fluids and solvents
- Mechanical protection in electrical installations
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable and long-lasting material reduces need for frequent replacements
- UV resistance extends product life, minimizing waste
- Protects electrical components, reducing risk of failure and electronic waste
Warranty Information
Standard manufacturer warranty applies; please refer to Cabac for specific warranty details.
Available Now
The Cabac Heatshrink Thin Wall 4.8MM Yellow Green 10M Box is available now for immediate purchase. Ideal for electrical insulation and protection in industrial and residential applications.
