Heavy Duty 32A 25m Extension Lead 5Pin 6mm² IP66 Grey Powersafe
This Powersafe heavy duty extension lead delivers 32A at 415V over a full 25 metres, built with 6mm² conductors and a 56 series 5 pin plug and socket suited to three phase power. UV stabilised and chemical resistant, it's IP66 rated for protection against dust and powerful water jets in harsh outdoor environments. Compliant with AS/NZS 3123 and AS/NZS 3820, it's built for construction sites, industrial workshops, and mining applications. Full specs and installation requirements are covered further down the page.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 25 Metre 32A 56 Style 5 Pin Plug and Socket | IP66 Rated | Heavy-Duty & UV Stabilised | by Powersafe
Brand: Powersafe
SKU: 6mm/25/32/56
Alternatively Known As: 32A 5 Pin Extension Lead, 56 Series Power Lead, Three Phase Extension Cord, Industrial Power Cable, 32 Amp 5 Pin Lead
Technical Specifications
- Cable Length: 25 metres
- Current Rating: 32A
- Voltage: 415V AC
- Plug & Socket: 56 Series, 5 pin (3 phase + neutral + earth)
- Cable Size: 6mm² conductors
- IP Rating: IP66 (dust tight and protected against powerful water jets)
- Cable Type: Heavy-duty, UV stabilised, chemical resistant
- Operating Temperature: -25°C to +75°C
- Dimensions (H x L x W): 120mm x 25000mm x 300mm
- Weight: 8.5 kg
Key Features
- 25 metre heavy-duty extension lead
- 32A current rating for high-powered equipment
- 56 Series 5 pin plug and socket for three-phase power
- IP66 rated for superior water and dust protection
- 6mm² cable for reliable power transmission
- UV stabilised and chemical resistant cable sheath
- Suitable for outdoor and harsh environments
Professional Installation Requirements
- Installation and connection should be performed by a licensed electrician to ensure compliance with Australian standards and site safety requirements.
Applications
- Construction sites requiring heavy-duty power distribution
- Industrial workshops and factories
- Outdoor events and temporary power setups
- Mining and resource sector applications
- Commercial maintenance and service work
Standards & Compliance
- Complies with AS/NZS 3123 – Industrial Plugs and Socket-Outlets
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable construction reduces replacement frequency and waste
- IP66 rating prevents ingress of contaminants, extending product lifespan
- UV and chemical resistance minimises environmental degradation
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Powersafe 25 metre 32A 56 style 5 pin plug and socket IP66 extension lead is available for immediate purchase. Ideal for industrial, construction, and outdoor power distribution applications.
FAQ
Q: What current and voltage rating does this extension lead have?
A: This Powersafe extension lead is rated to 32A at 415V, suited to construction sites, industrial workshops, and mining applications.
Q: Does this extension lead need to be installed by a licensed electrician?
A: Yes, installation and connection should be performed by a licensed electrician to ensure compliance with Australian standards and site safety requirements.
For a shorter run, the heavy duty 32A 15m extension lead with the same 5 pin 6mm² connector is also available.
Sites needing more length can step up to the heavy duty 32A 30m extension lead in grey
For higher current industrial jobs, the heavy duty 63A 25m extension lead with a CEE 16mm² connector is worth considering.
For three phase power distribution setups, the 3-phase extension lead guide covers compatible cable and connector types.
