Heavy Duty 50A 25m Extension Lead 5Pin 10mm² IP66 Grey Powersafe
This Powersafe heavy duty extension lead suits construction sites and industrial workshops needing high current temporary power over extended distances. It runs 25 metres with a 50A rating and 10mm² copper conductors for demanding equipment loads. The 56 Series 5 Pin plug and socket combination is IP66 rated and complies with AS/NZS 3123 for industrial plugs and socket-outlets. Full specifications and installation requirements are detailed further down the page.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: 25 Metre 50A 56 Style 5 Pin Plug and Socket | IP66 Rated | Heavy-Duty Flexible Cable | by Powersafe
Brand: Powersafe
SKU: 10mm/25/50/56
Alternatively Known As: 50A 5 Pin Extension Lead, 56 Series Power Lead, Industrial 5 Pin Plug and Socket, IP66 50A Extension Cable, Heavy Duty 5 Pin Power Lead
Technical Specifications
- Cable Length: 25 metres
- Current Rating: 50A
- Voltage: 415V AC
- Plug & Socket Type: 56 Series, 5 Pin
- Cable Size: 10mm² conductors
- Ingress Protection: IP66 (dust tight and protected against powerful water jets)
- Conductor Material: Copper
- Sheath: Heavy-duty flexible PVC
- Operating Temperature: -25°C to +60°C
- Dimensions (H x L x W): 120mm x 25000mm x 120mm
- Weight: 12 kg
Key Features
- 25 metre heavy-duty flexible cable for extended reach
- 50A current rating suitable for high power equipment
- 56 Series 5 pin plug and socket for secure, reliable connections
- IP66 rated for complete protection against dust and powerful water jets
- Robust construction for demanding industrial and outdoor use
Professional Installation Requirements
- Installation and connection should be performed by a licensed electrician to ensure compliance with Australian standards and site safety requirements.
Applications
- Construction sites requiring high current temporary power distribution
- Industrial workshops and factories
- Events and outdoor venues needing weatherproof power connections
- Mining and heavy-duty environments
Standards & Compliance
- Complies with AS/NZS 3123 – Industrial Plugs and Socket-Outlets
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Durable, reusable construction reduces waste from frequent replacements
- Weatherproof design minimizes risk of electrical faults and environmental contamination
Warranty Information
12 months manufacturer's warranty against defects in materials and workmanship.
Available Now
The Powersafe 25 metre 50A 56 style 5 pin plug and socket IP66 extension lead is available for immediate purchase. Ideal for construction, industrial, and outdoor applications requiring robust, weatherproof power distribution.
FAQ
Q: How long is this extension lead and what is its current rating?
A: This Powersafe extension lead runs 25 metres with a 50A current rating and 415V AC voltage.
Q: Is this extension lead suitable for outdoor construction or mining sites?
A: Yes, it is IP66 rated for dust and water protection and suited to construction, industrial and mining environments, and is backed by SCHNAP's 30-day return policy.
For shorter runs with the same current capacity, a 50A 20m extension lead offers a more manageable length.
Sites needing higher current for three-phase machinery often move up to a 63A extension lead.
Smaller equipment on the same site can be run off a braided 15A extension lead instead.
Crews unfamiliar with three-phase power setups can review the 3 phase extension lead guide beforehand.
Order with confidence — SCHNAP offers a 30-day return policy on electrical products.
