Hexagon Bolt DIN 960 | Strength Class 10.9 | Zinc-Nickel Plated | Fine Pitch M12 x 1.5 | @Pack of 5 | by Wurth
Hexagon Bolt DIN 960 with strength class 10.9 and zinc-nickel plating is perfect for high-strength mechanical assemblies. Designed for automotive and machinery construction, this fine pitch M12 x 1.5 bolt ensures reliable fastening with corrosion resistance of up to 720 hours. Ideal for precision engineering, it meets AS/NZS 4762 standards for structural applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagon Bolt DIN 960 | Strength Class 10.9 | Zinc-Nickel Plated | Fine Pitch M12 x 1.5 | @Pack of 5 | by Wurth
Brand: Wurth
SKU: 26341240
Alternatively Known As: Hex bolt M12 fine thread, Zinc nickel hex bolt, Fine pitch hex bolt, DIN 960 bolt, ISO 8765 bolt
Technical Specifications
- Thread type x nominal diameter x pitch: M12 x 1.5
- Length: 40 mm
- Head height: 7.5 mm
- Material: Steel
- Property class: 10.9
- Surface finish: Zinc nickel plating with transparent passivation (P3E)
- Corrosion protection period: 720 hours according to DIN EN ISO 9227-NSS
- Head type: Hexagon head
- Drive type: Outer hexagon (WS19)
- Thread form: Fine pitch thread
- Thread design: Partial thread
- Shank diameter: 12 mm
- Thread length: 22 mm
- RoHS-compliant: Yes
- Product class: A
- Dimensions (H x L x W): 7.5mm x 40mm x 19mm
- Weight: 0.05 kg
Key Features
- Chromium (VI)-free compliant with EU End of Life Vehicles Directive
- Corrosion resistance of 720 hours base metal corrosion according to DIN EN ISO 9227-NSS
- Fine pitch metric thread M12 x 1.5 with partial thread design
- Hexagon head with outer hexagon drive (WS19)
- Zinc-nickel plated surface with transparent passivation (P3E)
- Strength class 10.9 steel material
Professional Installation Requirements
- Installation by qualified personnel using appropriate torque tools is recommended to ensure proper fastening and safety.
Applications
- Mechanical assemblies requiring high strength fasteners
- Automotive and machinery construction
- Industrial equipment fastening
- Precision engineering requiring fine pitch threads
Standards & Compliance
- Complies with AS/NZS 4762 for high strength steel bolts used in structural applications
Environmental Benefits
- Chromium (VI)-free plating reduces environmental and health hazards
- Complies with EU End of Life Vehicles Directive promoting sustainable recycling
Warranty Information
Standard manufacturer warranty against defects in material and workmanship.
Available Now
Available for immediate purchase, ideal for industrial, automotive, and mechanical fastening applications.
