Hexagon Nut ASME B18.2.2 | GR8 Steel | Blue Passivated Zinc Plated | UNC Thread | @PCS of 1 | by Wurth
Hexagon Nut ASME B18.2.2 made from GR8 steel and featuring a blue passivated zinc plated surface is perfect for mechanical assemblies and industrial applications. With UNC threading and high corrosion resistance, this nut ensures durability and reliability in automotive and construction projects. Ideal for professionals seeking quality fastening solutions.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagon Nut ASME B18.2.2 | GR8 Steel | Blue Passivated Zinc Plated | UNC Thread | @PCS of 1 | by Wurth
Brand: Wurth
SKU: 7739016
Alternatively Known As: Hex Nut, Inch Hex Nut, UNC Hex Nut, Blue Zinc Plated Nut, GR8 Steel Nut
Technical Specifications
- Nominal diameter: 1 inch (25.4 mm)
- Height: 0.887 inch (22.5 mm)
- Width across flats: 1 1/2 inch (38 mm)
- Material: Steel
- Property class: GR8
- Surface finish: Blue passivated zinc plated
- Thread type: UNC
- Threads per inch: 8
- Mechanical properties regulated by SAE J995
- Thread tolerance: ASME B1.1 = 2B (internal thread)
- Dimensions (H x L x W): 22.5mm x 38mm x 38mm
- Weight: 0.1 kg
Key Features
- Made from GR8 steel for high strength
- Blue passivated zinc plated surface for corrosion resistance
- Complies with ASME B18.2.2 standard for hexagon nuts
- UNC thread type with 8 threads per inch
- Standard thread tolerance according to ASME B1.1 = 2B for internal thread
Professional Installation Requirements
- Installation by a qualified technician or engineer is recommended to ensure proper torque and fitment.
Applications
- Mechanical assemblies requiring inch-sized hexagon nuts
- Industrial machinery and equipment
- Automotive and construction applications
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Durable zinc plating extends product life reducing waste
- High strength material reduces need for frequent replacements
Warranty Information
Standard manufacturer warranty against defects applies.
Available Now
The Wurth Hexagon Nut inch size is available for immediate purchase, ideal for industrial and mechanical fastening applications.
