Hexagonal Head Sleeve Bolt Anchor | 8mm Diameter | Mechanically Galvanised | Heavy Duty Load Anchor | @Each by Wattmaster
The Hexagonal Head Sleeve Bolt Anchor is designed for heavy-duty anchoring in concrete and masonry, featuring an 8mm diameter and a mechanically galvanised finish for enhanced corrosion resistance. Ideal for securing structural supports and machinery, this fully assembled anchor ensures strong holding power through its expansion and friction design, making it perfect for construction and industrial applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hexagonal Head Sleeve Bolt Anchor | 8mm Diameter | Mechanically Galvanised | Heavy Duty Load Anchor | @Each by Wattmaster
Brand: Wattmaster
SKU: ALCGFBAH840
Alternatively Known As: Hex Head Sleeve Bolt Anchor, Expansion Sleeve Bolt, Galvanised Sleeve Anchor, Heavy Duty Sleeve Bolt
Technical Specifications
- Material: Mechanically galvanised steel
- Diameter: 8mm
- Length: 40mm
- Type: Hexagonal head sleeve bolt anchor
- Anchor Type: Expansion and friction anchor
- Finish: Mechanically galvanised for corrosion resistance
- Assembly: Fully assembled
- Dimensions (H x L x W): 40mm x 40mm x 8mm
- Weight: 0.1 kg
Key Features
- Hex flanged head for a flush finish
- Heavy duty load anchor providing strong holding power
- Expansion and friction anchor for secure fixing
- Fully assembled for ease of installation
- Mechanically galvanised for enhanced corrosion resistance
Professional Installation Requirements
- Installation should be performed by a qualified professional to ensure correct anchoring and load capacity compliance.
Applications
- Heavy duty load anchoring in concrete and masonry
- Fixing structural supports, machinery, and equipment
- Suitable for construction, industrial, and maintenance applications
Standards & Compliance
- Complies with AS/NZS 1170 – Structural Design Actions (Wind, Earthquake, Snow Loads)
Environmental Benefits
- Galvanised coating extends product life reducing waste and replacement frequency
Warranty Information
Warranty against manufacturing defects as per Wattmaster standard policy.
Available Now
The Hexagonal Head Sleeve Bolt Anchor 8mm x 40mm by Wattmaster is available for immediate purchase, ideal for heavy duty anchoring in construction and industrial applications.
