HL18-B2B3BD | Photoelectric sensors
The SICK HL18-B2B3BD is a compact photoelectric retro-reflective sensor featuring a dual lens system, visible red PinPoint LED light, and robust IP67/IP69K protection, ideal for precise object detection in industrial automation.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18-B2B3BD | Photoelectric sensors
Brand: SICK
SKU: 1090937
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, M18 photoelectric sensor, SICK HL18 sensor, Industrial object sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: PNP, light switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Light wavelength: 631 nm
- Light spot size at 6.5 m: 130 mm x 260 mm
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Protection class: III
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +70 °C
- Storage temperature: -40 °C to +75 °C
- Connection: Cable with M8 3-pin connector, 150 mm
- Circuit protection: A, B, D types
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red light with PinPoint LED light source
- Sensing range from 0.03 m to 6.5 m
- Signal strength light bar for easy adjustment
- M18 threaded housing with hybrid light emission design
- IP67 and IP69K rated for dust and water protection
- Operating temperature range from -40 °C to +70 °C
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- PNP switching output with light switching mode
- Cable with M8 3-pin connector, 150 mm length
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure proper mounting, wiring, and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in production lines
- Material handling and packaging systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable IP67/IP69K housing reduces waste by extending product life
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HL18-B2B3BD Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
