HL18-P2B3AA | Photoelectric sensors
The SICK HL18-P2B3AA is a robust photoelectric retro-reflective sensor designed for precise object detection in industrial automation, featuring a dual lens system and high protection ratings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18-P2B3AA | Photoelectric sensors
Brand: SICK
SKU: 1071049
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, SICK HL18 sensor, Industrial photo sensor, M18 photoelectric sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.03 m to 6.5 m
- Light source: PinPoint LED, visible red light at 631 nm wavelength
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: PNP, light switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: Cable with M8 3-pin connector, 150 mm length
- Housing material: Plastic VISTAL®, optics material: PMMA
- Enclosure rating: IP67 and IP69K
- Operating temperature: –40 °C to +70 °C
- Weight: 18 g
- Dimensions (H x L x W): 46mm x 32mm x 16mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red light with PinPoint LED light source
- Sensing range from 0.03 m to 6.5 m
- Hybrid housing design with M18 thread diameter
- IP67 and IP69K rated for dust and water protection
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- Polarizing filter included to reduce false triggering
- Operating temperature range from –40 °C to +70 °C
- Cable with M8 3-pin connector, 150 mm length
Professional Installation Requirements
- Installation by a qualified technician or electrician is recommended to ensure proper mounting, wiring, and compliance with safety standards.
Applications
- Industrial automation for object detection
- Manufacturing process control
- Safety and monitoring in production lines
- Material handling and packaging systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with efficient LED light source
- Durable IP67/IP69K housing reduces waste by extending product life
- Complies with RoHS for reduced hazardous substances
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HL18-P2B3AA Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and manufacturing applications.
