HL18G-P0Z3BLS15 | Photoelectric sensors
The SICK HL18G-P0Z3BLS15 is a robust photoelectric retro-reflective sensor designed for precise object detection including transparent objects, featuring a dual lens system and high protection ratings for industrial environments.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18G-P0Z3BLS15 | Photoelectric sensors
Brand: SICK
SKU: 1096539
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, SICK HL18G sensor, Industrial object sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.1 m to 2.5 m
- Light source: PinPoint LED, visible red light at 631 nm wavelength
- Switching output: PNP complementary with light/dark switching modes
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1000 Hz
- Supply voltage: 10 V DC to 30 V DC with ripple < 5 V pp
- Protection class: III
- Enclosure rating: IP67 and IP69K
- Housing material: Plastic VISTAL®, optics material: PMMA
- Operating temperature: -40°C to +70°C
- EMC compliance: EN 60947-5-2 industrial radio safety class A
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system
- Visible red light with PinPoint LED light source
- Sensing range from 0.1 m to 2.5 m
- AutoAdapt feature for automatic adjustment
- Signal strength light bar for easy monitoring
- Polarizing filter to reduce false signals
- Housing made of durable VISTAL® plastic
- High protection rating IP67 and IP69K
- Operating temperature range from -40°C to +70°C
- Fast response time ≤ 0.5 ms and switching frequency up to 1000 Hz
Professional Installation Requirements
- Installation by qualified personnel is recommended to ensure correct mounting and electrical connection according to industrial safety standards.
Applications
- Industrial automation for object detection
- Detecting transparent objects in manufacturing
- Use in harsh environments requiring IP67/IP69K protection
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable housing reduces waste and replacement frequency
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK HL18G-P0Z3BLS15 photoelectric sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
