HL18L-B3G5BE | Photoelectric sensors
The SICK HL18L-B3G5BE is a high-performance photoelectric retro-reflective sensor designed for precise detection of small objects in industrial automation applications, featuring a durable IP67/IP69K rated housing and laser light source.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18L-B3G5BE | Photoelectric sensors
Brand: SICK
SKU: 1071028
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, Laser sensor, Object detection sensor, Industrial photo sensor
Technical Specifications
- Functional principle: Photoelectric retro-reflective sensor with dual lens system
- Sensing range: 0.1 m to 12 m
- Light source: Visible red laser, 655 nm wavelength, Laser class I
- Supply voltage: 10 V DC to 30 V DC with ripple < 5 V pp
- Current consumption: ≤ 20 mA
- Switching output: PNP and NPN, light switching mode
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1,000 Hz
- Connection: Cable with M8 male connector, 4-pin, 2,000 mm
- Protection class: III
- Enclosure rating: IP67 and IP69K
- Operating temperature: -30 °C to +55 °C
- Storage temperature: -40 °C to +70 °C
- Housing material: Plastic VISTAL®, optics material: Plastic PMMA
- Weight: 18 g
- EMC compliance: EN 60947-5-2
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system for minimum distance to reflector
- Visible red laser light source with 655 nm wavelength
- Sensing range from 0.1 m up to 12 m
- Signal strength light bar for easy adjustment
- IP67 and IP69K rated for dust and water protection
- Housing made of durable plastic VISTAL® with blue color
- Fast response time of ≤ 0.5 ms and switching frequency of 1,000 Hz
- Light/dark switching potentiometer for flexible operation
- Polarizing filter included to reduce interference
- Cable with M8 male connector, 4-pin, 2,000 mm length
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with photoelectric sensor wiring and safety standards to ensure proper operation and compliance.
Applications
- Industrial automation for detecting small objects
- Manufacturing process control
- Material handling and packaging systems
- Safety and presence detection in machinery
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with supply voltage from 10 V DC to 30 V DC
- Durable IP67/IP69K housing reduces environmental damage and extends product life
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK HL18L-B3G5BE Photoelectric Retro-Reflective Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
