HL18T-P2G3BB | Photoelectric sensors
The SICK HL18T-P2G3BB is a durable photoelectric retro-reflective sensor designed for precise object detection including transparent objects, featuring a dual lens system and robust IP67/IP69K rated housing.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18T-P2G3BB | Photoelectric sensors
Brand: SICK
SKU: 1079923
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, Optical sensor, Object detection sensor, SICK HL18T sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: PNP, light switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1000 Hz
- Protection class: III
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +70 °C
- Storage temperature: -40 °C to +75 °C
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Cable: Plastic PVC, 0.2 mm² conductor cross section
- Mounting: M18 thread, head/side mount
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system
- Visible red light with PinPoint LED at 631 nm wavelength
- Sensing range from 0.1 m to 2.5 m (max 3 m)
- Signal strength light bar for easy adjustment
- Polarizing filter included to reduce false signals
- Robust plastic VISTAL® housing with IP67 and IP69K protection
- Fast response time ≤ 0.5 ms and switching frequency up to 1000 Hz
- Cable with M8 3-pin connector, 2,000 mm length
Professional Installation Requirements
- Installation by a qualified electrician or technician is recommended to ensure proper wiring and sensor alignment for optimal performance.
Applications
- Industrial automation for object detection
- Detecting transparent objects in manufacturing
- Use in harsh environments requiring IP67/IP69K protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low power consumption with ≤ 20 mA current draw
- Durable design reduces waste and replacement frequency
- Complies with China RoHS for hazardous substance restrictions
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK HL18T-P2G3BB Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
