HL18T-P3B3BB | Photoelectric sensors
The SICK HL18T-P3B3BB is a robust photoelectric retro-reflective sensor designed for precise object detection including transparent objects, featuring a dual lens system, visible red light, and high ingress protection for industrial applications.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: HL18T-P3B3BB | Photoelectric sensors
Brand: SICK
SKU: 1095544
Alternatively Known As: Photoelectric sensor, Retro-reflective sensor, Optical sensor, Industrial object sensor, SICK HL18T sensor
Technical Specifications
- Supply voltage: 10 V DC to 30 V DC
- Current consumption: ≤ 20 mA
- Switching output: PNP complementary with light/dark switching
- Output current max: ≤ 100 mA
- Response time: ≤ 0.5 ms
- Switching frequency: 1000 Hz
- Connection: Cable with M8 male connector, 4-pin, 150 mm
- Cable material: Plastic, PVC
- Conductor cross section: 0.2 mm²
- Protection class: III
- Enclosure rating: IP67, IP69K
- Operating temperature: -40 °C to +70 °C
- Storage temperature: -40 °C to +75 °C
- Housing material: Plastic, VISTAL®
- Optics material: Plastic, PMMA
- Polarizing filter included
- Dimensions (H x L x W): 45.5mm x 31.8mm x 16.2mm
- Weight: 0.1 kg
Key Features
- Photoelectric retro-reflective sensor with dual lens system
- Visible red light with PinPoint LED at 631 nm wavelength
- Sensing range from 0.1 m to 2.5 m (max 3 m)
- Signal strength light bar for easy adjustment
- Housing made of durable VISTAL® plastic with PMMA optics
- IP67 and IP69K rated for dust and water protection
- Polarizing filter included to reduce false signals
- Fast response time ≤ 0.5 ms and switching frequency up to 1000 Hz
- Complementary PNP switching outputs with light/dark switching modes
- Wide operating temperature range from -40 °C to +70 °C
Professional Installation Requirements
- Installation should be performed by qualified personnel familiar with industrial sensor wiring and safety standards.
Applications
- Industrial automation for object detection
- Detecting transparent objects in manufacturing
- Use in harsh environments requiring IP67/IP69K protection
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces replacement frequency and waste
- Low power consumption (≤ 20 mA) supports energy efficiency
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy.
Available Now
The SICK HL18T-P3B3BB Photoelectric Sensor is available for immediate purchase, ideal for industrial automation and object detection applications.
