Hour Meter 240V | Digital Display | DIN Rail Modular Mount | IP20 Rated | @Pack of 1 | by Clipsal
The Hour Meter 240V is designed to accurately record equipment operating hours, featuring a clear digital display and a modular DIN rail mount for easy installation. Ideal for industrial and commercial applications, it ensures efficient maintenance scheduling and energy conservation by monitoring equipment usage.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Hour Meter 240V | Digital Display | DIN Rail Modular Mount | IP20 Rated | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCH15440
Alternatively Known As: Hour Counter, DIN Rail Hour Meter, 230V Hour Meter, Equipment Run Time Meter, Clipsal SCH15440
Technical Specifications
- Operating Voltage: 230-240V AC
- Mounting: DIN rail modular
- Display: Digital hour counter
- Frequency: 50/60Hz
- Power Consumption: <2VA
- Operating Temperature: -10°C to +50°C
- Reset: Non-resettable
- Ingress Protection: IP20 (front panel)
- Dimensions (H x L x W): 90mm x 65mm x 18mm
- Weight: 0.15 kg
Key Features
- Accurately records equipment operating hours
- Modular DIN rail mount design for easy installation
- 230-240V AC operation
- Clear digital display for easy reading
- Long-life, maintenance-free operation
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules.
Applications
- Industrial equipment monitoring
- Commercial machinery usage tracking
- Panel boards and switchboards
- HVAC systems
- Generators and pumps
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables efficient maintenance scheduling, reducing unnecessary servicing and resource use.
- Promotes energy conservation by monitoring equipment usage.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal Hour Meter 240V SCH15440 is available for immediate purchase. Ideal for industrial and commercial applications requiring accurate equipment run time monitoring.
