Infrared Motion Sensor 180° | IP44 Rated | Black Finish
Infrared motion sensor with 180° detection range and IP44 rating—ideal for outdoor security. Built for LED compatibility, with manual override and adjustable ambient light settings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Infrared Motion Sensor 180° | IP44 Rated | Black Finish
SKU: ST09 BLK
Alternatively Known As: PIR Motion Sensor, Infrared Occupancy Sensor, Motion Detector Switch
Technical Specifications
- Input Voltage: 220V-240V
- Detection Range: 180°
- Installation Height: 2.2m-4.0m
- Detection Motion Speed: 0.6-1.5m/s
- Detection Distance: 12m Max
- Time Delay: Min. 10Sec + 3Sec, Max. 15min + 2min
- Ambient Light Sensitivity: <3-2000 LUX (adjustable)
- Wiring: 3 wires
- Dimensions (H x L x W): 50mm x 80mm x 80mm
- Weight: 0.3 kg
Key Features
- Surface mounted design
- 180° detection range
- Manual override function
- Suitable for LED lighting
- IP44 rated for dust and water resistance
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended to ensure compliance with electrical safety standards.
Applications
- Residential: Home security and automation
- Commercial: Office lighting control and security
- Industrial: Warehouse and factory motion detection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Energy saving by automatically controlling lighting based on occupancy
- Reduces unnecessary power consumption and carbon footprint
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Infrared Motion Sensor 180° IP44 Rated in Black Finish is available now for immediate purchase. Ideal for enhancing security and energy efficiency in residential, commercial, and industrial applications.
