Integrated Solar Street Light 1400lm 6500K MajorTech
MajorTech solar street light features 1400 lumens, an integrated panel and 6500K output. Ideal for street, path and area lighting.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: MajorTech SSL80C, 10W Solar Street Light, Integrated Solar Path Light, Solar Area Light
Technical Specifications
- Luminous Output: 1400 lm
- Actual Power: 10 W
- Luminous Efficacy: 140 lm/W
- Colour Temperature: 6500K cool white
- LED Type: SMD5054
- Battery Type: LiFePO4
- Battery Specification: 3.2 V, 10,000 mAh
- Solar Panel: 10 W/5 V integrated monocrystalline silicon and glass
- Discharge Time: 12–14 hours typical
- Charging Time: 4–6 hours at 40,000 lux
- Charging Cycles: More than 1200
- PIR Detection Distance: Up to 8 m
- PIR Detection Angle: 120°
- Beam Angle: 120°
- Ingress Protection: IP54
- Operating Temperature: -10°C discharge; 5°C to 40°C charge
- Operating Humidity: Less than 95% RH
- Installation Height: 3–6 m pole mounted
- Pole Diameter: 48 mm
- Light Modes: Day/night auto, continuous on/off, preset times and PIR motion activation
- Included Accessories: Remote control, 2 x AAA batteries, pole mount bracket, nuts and bolts
- Dimensions (H x L x W): 47mm x 413mm x 231mm
- Weight: 1.2 kg
Key Features
- Integrated monocrystalline solar panel and rechargeable LiFePO4 battery
- 1400-lumen output with 6500K cool white light
- PIR motion activation up to 8 m with a 120° detection angle
- Remote-controllable lighting modes
- IP54 UV-resistant ABS housing for outdoor use
- Up to 14 hours of illumination after a full charge in optimal sunlight
- Suitable for mounting to existing poles
- Battery charging level and lighting mode indicator
Professional Installation Requirements
- Installation should be completed by a competent installer. Secure the included pole mount bracket to a suitable pole or mounting arm and position the integrated solar panel for maximum sunlight exposure. Follow the manufacturer's installation instructions and applicable local electrical and structural requirements.
Applications
- Street lighting
- Pathway and pedestrian-area lighting
- Residential road lighting
- Parking-area lighting
- Outdoor area lighting
- Remote or off-grid lighting locations
Standards & Compliance
- AS/NZS 60598.2.3:2015 — applicable particular requirements for road and street lighting luminaires; manufacturer compliance is not stated
- AS/NZS 1158 series — applicable design and performance guidance for lighting roads and public spaces; project-specific compliance requires lighting assessment
Environmental Benefits
- Solar-powered operation reduces reliance on grid electricity during use
- Rechargeable LiFePO4 battery supports more than 1200 charging cycles
- Integrated solar generation enables off-grid operation and reduces cabling requirements
- Durable UV-resistant housing can help extend service life and reduce replacement waste
Warranty Information
Two-year limited warranty for Major Tech solar lighting, subject to the manufacturer's warranty terms and exclusions.
Available Now
Available through Major Tech and authorised Australian distributors, subject to distributor stock.
