IO-Link Wireless Gateway | IP67 Rated | Supports 64 IO-Link Devices | Wireless Communication Up to 20m | by SICK
The IO-Link Wireless Gateway is designed for seamless industrial automation, enabling wireless integration of up to 64 IO-Link devices. With an IP67 rating for dust and water protection, it supports various communication interfaces including Ethernet and OPC UA, making it ideal for IIoT applications. Experience efficient real-time data exchange and reduced cabling requirements, perfect for enhancing operational efficiency in industrial settings.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: IO-Link Wireless Gateway | IP67 Rated | Supports 64 IO-Link Devices | Wireless Communication Up to 20m | by SICK
Brand: SICK
SKU: 6087627
Alternatively Known As: Wireless IO-Link Gateway, Industrial Wireless Gateway, IO-Link Master Wireless, IIoT Wireless Gateway
Technical Specifications
- Communication interfaces: Ethernet, EtherCAT®, REST API, OPC UA
- Enclosure rating: IP67 for dust and water protection
- Radio approval: 3 SMA antennas, 2 track, Unlicensed 2.4GHz ISM band, Tx power 10 dBm max, Rx Sensitivity PER 30% @ -92 dBm or better
- IO-Link or DI/DO Ports: 2x M12, 5-pin, L-coded power In/Out; 2x M12 Ports, 5-pin, D-coded
- Functions: Initial setup, configuration and monitoring via WIE, internal Web Server interface or PLC
- Dimensions (H x L x W): 80mm x 150mm x 120mm
- Weight: 1.5 kg
Key Features
- Wireless communication up to 20 m
- Supports up to 64 IO-Link devices per master
- Interference-free frequency hopping method
- Data transmission with short delay time
- IIoT integration via OPC-UA, MQTT, REST API
- Fieldbus integration with PROFINET, EtherNet/IP, EtherCAT
- Compact IP67 rated design
- Interlinking to reduce power cabling
Professional Installation Requirements
- Installation and configuration should be performed by qualified industrial automation professionals to ensure proper integration and compliance with safety standards.
Applications
- Industrial automation for wireless integration of IO-Link devices
- IIoT platform connectivity
- PLC communication and control
- Mobile and long-distance wireless communication applications
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Reduces cabling requirements, minimizing material use and installation waste
- Supports wireless communication reducing the need for physical infrastructure
- Enables efficient real-time data exchange improving operational efficiency
Warranty Information
Standard manufacturer warranty of 2 years covering defects in materials and workmanship.
Available Now
The SICK IO-Link Wireless Gateway is available for immediate purchase, ideal for industrial automation and IIoT wireless communication applications.
