Isolation Busbar Chassis 250A | 96 Way 2Pole | Universal Red Black by NHP
Isolation busbar chassis with 250A rated current and 96 poles—ideal for industrial power distribution. Built for durability with encapsulated housing and IP20 protection, suitable for indoor use.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP POWERMAX GB Isolation Busbar Chassis DIN-T 250A 96 Way 2Pole Universal Red Black
Brand: NHP
SKU: GB296182U
Alternatively Known As: NHP Busbar, Isolation Busbar, DIN-T Busbar, Power Distribution Busbar
Technical Specifications
- Rated Current: 250 A
- Number of Poles: 96
- Nominal Voltage: 415 V
- Short Time Withstand Current (0.2 sec): 25 kA
- Short Time Withstand Current (0.3 sec): 20 kA
- Short Time Withstand Current (1 sec): 10 kA
- Assembly Arrangement: 18mm pitch
- Material Housing: Encapsulated material
- Degree of Protection: IP20
- Dimensions (H x L x W): 896mm x 82mm x 100mm
- Weight: 5 kg
Key Features
- 250A rated current with 96 poles for versatile applications.
- Encapsulated housing for enhanced durability and safety.
- IP20 protection rating suitable for indoor use.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Power distribution in commercial and industrial settings
- Electrical: Suitable for use in switchboards and distribution boards
Standards & Compliance
- Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
- Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP POWERMAX GB Isolation Busbar Chassis DIN-T 250A 96 Way 2Pole Universal Red Black is available now for immediate purchase. Ideal for industrial power distribution applications.
