Isolation Busbar Chassis 250A | 96 Way 4Pole | Bottom Feed by NHP

BRAND: NHP
SKU: GB296184BF
$4,375.70 List price: $5,810.40
+
Isolation busbar chassis with 250A rated current and 96 poles—ideal for industrial power distribution. Built for durability with encapsulated housing and IP20 protection, perfect for switchboards and distribution boards.

Product Name/Title: NHP POWERMAX GB Isolation Busbar Chassis DIN-T 250A 96 Way 4Pole Bottom Feed RNWNBN

Brand: NHP

SKU: GB296184BF

Alternatively Known As: NHP Busbar, Isolation Busbar, Power Distribution Busbar

Technical Specifications
  • Rated Current: 250 A
  • Number of Poles: 96
  • Nominal Voltage: 415 V
  • Short Time Withstand Current (0.2 sec): 25 kA
  • Short Time Withstand Current (0.3 sec): 20 kA
  • Short Time Withstand Current (1 sec): 10 kA
  • Assembly Arrangement: 18mm pitch
  • Degree of Protection: IP20
  • Dimensions (H x L x W): 896mm x 82mm x 300mm
  • Weight: 10 kg
Key Features
  • 250A rated current with 96 poles for extensive connectivity.
  • Encapsulated material housing for enhanced durability.
  • IP20 degree of protection suitable for indoor use.
Professional Installation Requirements
  • Professional installation by a qualified electrician is required for safety and compliance.
Applications
  • Industrial: Power distribution in commercial and industrial settings
  • Electrical: Suitable for use in switchboards and distribution boards
Standards & Compliance
  • Complies with AS/NZS 3000 for electrical installations.
Environmental Benefits
  • Durable materials reduce the need for frequent replacements, minimizing waste.
Warranty Information

1 year warranty against manufacturing defects.

Available Now

The NHP POWERMAX GB Isolation Busbar Chassis DIN-T 250A 96 Way 4Pole Bottom Feed is available now for immediate purchase. Ideal for industrial and electrical applications.

Non-Returnable & Non-Cancellable

GB296184BF-AU-Chassis-GB-DINT-250A-4-Pole-Bottom-Feed-Datasheet.pdf (GB296184BF-AU-Chassis-GB-DINT-250A-4-Pole-Bottom-Feed-Datasheet.pdf, 304 Kb) [Download]
