Junction Box IP65 150x110x70mm Grey MajorTech
MajorTech junction box features IP65 rating and 150x110x70mm dimensions in grey. Ideal for weatherproof cable connections.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: VETi VJ15117G Junction Box, Weatherproof Junction Box, ABS Electrical Enclosure, Cable Junction Box
Technical Specifications
- Ingress Protection: IP65
- Impact Resistance: IK08
- Material: Non-flammable ABS plastic
- Shape: Rectangular
- Cable Entry: 10 multiple knock-outs
- Knock-Out Sizes: 20 mm and 28 mm options per hole
- Ambient Temperature: -5°C to 40°C
- Storage Temperature: 40°C to 75°C, maximum 95% humidity
- Manufacturer Standards: IEC 60529 and IEC 60670
- Manufacturer Approvals: CE, RoHS, HF test, IK test and ISO 9001 manufacturing
- Dimensions (H x L x W): 70mm x 150mm x 110mm
- Weight: 0.2 kg
Key Features
- IP65 protection against dust ingress and water jets
- Ten pre-formed knock-outs for flexible cable entry
- Durable, non-flammable ABS plastic construction
- IK08 protection against mechanical impact
- Suitable for indoor and light outdoor electrical connections
- Grey finish for discreet installation
- Compact rectangular enclosure for residential, commercial and industrial applications
Professional Installation Requirements
- For fixed mains-voltage wiring, installation should be carried out by a licensed electrician in accordance with AS/NZS 3000. Cable entries and knock-outs must be correctly fitted and sealed to maintain the IP65 rating.
Applications
- Indoor electrical cable junctions
- Outdoor and weather-exposed cable connections
- Residential electrical installations
- Commercial building services
- Industrial control and low-voltage wiring enclosures
- HVAC, refrigeration and equipment cable connections
Standards & Compliance
- AS/NZS IEC 60670.22:2012: Relevant Australian/New Zealand requirements for connecting boxes and enclosures used for junctions and tappings; manufacturer specifies IEC 60670
- AS/NZS 3000:2018: Installation requirements applicable when the enclosure is used within a fixed electrical installation
- IEC 60529: Manufacturer-specified reference standard for the IP65 ingress protection rating
Environmental Benefits
- ABS plastic construction can be recycled through appropriate plastics recycling streams
- RoHS approval indicates restriction of specified hazardous substances
- Durable IP65 and IK08 construction can extend service life and reduce replacement waste
- Non-flammable insulating material may reduce reliance on metallic enclosure components in suitable applications
Warranty Information
Five-year limited warranty for the VETi IP55/IP65 junction box range, subject to MajorTech warranty terms and conditions.
Available Now
Available through MajorTech and authorised Australian electrical distributors.
