Lockwood EMZ8 U Bracket for 12mm Glass | 450Kg Holding Force | Hall/Bond Monitoring | Fail Safe Operation | by Lockwood
The Lockwood EMZ8 U Bracket for 12mm glass is designed for secure electromagnetic locking, offering a robust 450Kg holding force and advanced Hall/Bond monitoring. Ideal for commercial swing doors and high-use applications, this bracket ensures reliable performance with fail-safe operation and smart electronics for instantaneous release.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Lockwood EMZ8 U Bracket for 12mm Glass | 450Kg Holding Force | Hall/Bond Monitoring | Fail Safe Operation | by Lockwood
Brand: Lockwood
SKU: EMZ8B-GU
Alternatively Known As: EMZ8 Glass U Bracket, Electromagnetic Lock Bracket for Glass Doors, Lockwood EMZ8 Glass Mount
Technical Specifications
- Nominal Holding Force: 450Kg
- Dimensions: 266mm (L) x 72mm (H) x 40mm (D)
- Voltage: 12Vdc / 24Vdc ±10%
- Current: 512mA @ 12Vdc, 256mA @ 24Vdc
- Monitoring: Hall-Effect/Bond sensing & Reed Switch
- Operating Temperature: -10 to 55°C
- Operating Humidity: 0 - 95%
- Dimensions (H x L x W): 72mm x 266mm x 40mm
- Weight: 1.5 kg
Key Features
- Operates with holding forces from 200kg to 450kg
- Hall/Bond monitoring indicates lock power and magnetic bonding
- Integrated reed switch monitors door position separately
- Constructed with aluminium case and heavy duty electromagnet
- Fail safe mode operation with secondary lock or battery backup system
- Smart electronics with zero residual magnetism for instantaneous release
Professional Installation Requirements
- Professional installation by a qualified locksmith or security system installer is recommended to ensure proper mounting and electrical connections.
Applications
- Suitable for glass door installations requiring electromagnetic locking
- Ideal for commercial swing doors and high use doors
- Compatible with wood, aluminium, steel, and glass door constructions
Standards & Compliance
- Complies with AS/NZS 4801 – Occupational Health & Safety Management Systems
Environmental Benefits
- Fail safe operation reduces energy consumption during power outages
- Durable aluminium construction extends product lifespan, reducing waste
Warranty Information
Standard manufacturer warranty applies. Please refer to Lockwood for specific warranty details.
Available Now
The Lockwood EMZ8 U Bracket 12mm Glass is available for immediate purchase, ideal for secure glass door electromagnetic lock installations.
