Long Range UHF RFID Reader | 10m Read Range | IP67 Rated | Adjustable Power | by SICK
The Long Range UHF RFID Reader RFU630-13106 offers exceptional read/write capabilities with a range of up to 10 meters, making it ideal for industrial asset tracking and logistics automation. Built with a robust aluminum die cast housing and an IP67 rating, this device is designed to withstand harsh environments while providing multiple industrial communication interfaces for seamless integration.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Frequency band: UHF 860 MHz to 960 MHz
- Carrier frequency: 916.8 MHz to 920.4 MHz
- Output power: 4 W EIRP with integrated antenna, adjustable up to 30 dBm at external antenna port
- Antenna: Integrated circular polarized, axial ratio typically 2 dB, front-to-back ratio > 17 dB
- Read range: Up to 10 meters
- Supply voltage: 18 V DC to 30 V DC
- Power consumption: Typically 20 W
- Housing material: Aluminum die cast
- Enclosure rating: IP67
- Protection class: III
- Interfaces: Ethernet (TCP/IP, OPC UA), PROFINET, EtherNet/IP, EtherCAT, Serial (RS-232, RS-422), CAN, PROFIBUS DP, USB 2.0, CANopen
- Digital inputs/outputs: 2 physical inputs and outputs each, with additional logical inputs/outputs via optional modules
- Operating temperature: -30°C to +60°C
- Storage temperature: -30°C to +70°C
- Relative humidity: Up to 90%, non-condensing
- EMC: EN 301489-3
- Vibration resistance: EN 60068-2-64
- Shock resistance: EN 60068-2-27
- MTBF: Greater than 100 years
- Dimensions (H x L x W): 64mm x 239mm x 239mm
- Weight: 2.6 kg
Key Features
- Long range UHF RFID read/write capability with up to 10 m read range
- Integrated circular polarized antenna with adjustable transmitting power
- Supports EPCglobal UHF Class 1 Gen 2, ISO/IEC 18000-6C, and RAIN RFID standards
- Multiple external antenna connections with adjustable power up to +30 dBm
- Robust aluminum die cast housing with IP67 rating for harsh environments
- Wide operating temperature range from -30°C to +60°C
- Multiple industrial communication interfaces including Ethernet, PROFINET, EtherNet/IP, EtherCAT, Serial, CAN, PROFIBUS DP, USB, and CANopen
- Advanced diagnostics, firmware updates, and programmable data output formats
- Equipped with optical and acoustic indicators and web server for operator interface
Professional Installation Requirements
- Professional installation by a qualified technician or electrician is recommended to ensure proper setup, configuration, and compliance with electrical standards.
Applications
- Industrial asset tracking and management
- Logistics and warehouse automation
- Manufacturing process control
- Supply chain management
- Bulk reading of RFID tags in harsh environments
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enables efficient asset tracking reducing waste and loss
- Supports automation to optimize resource use and reduce energy consumption
- Durable IP67 rated housing extends product life reducing electronic waste
Warranty Information
Standard manufacturer warranty applies; please refer to SICK's official warranty policy for details.
Available Now
The SICK RFU630-13106 Long Range RFID Read/Write Device is available for immediate purchase, ideal for industrial and logistics applications requiring reliable RFID solutions.
