MCB 2P 1A D Curve 133VAC Acti9 Clipsal

BRAND: Clipsal
SKU: SCHA9F45201
$76.60 List price: $95.50
+ −
30 Days Return Electricians Unlock Trade Access
Clipsal MCB D Curve AC features 20000 cycles, 10000 cycles and 500V AC. 2P, 1A, D curve, 6000A breaking capacity. Ideal for homes, apartments, offices.
Technical Specifications
  • Rated operational voltage: 12...133 V AC, 220...240 V AC, 380...415 V AC, 440 V AC, 100...133 V DC
  • Mechanical durability: 20,000 cycles
  • Electrical durability: 10,000 cycles
  • Rated insulation voltage: 500 V AC
  • Rated impulse withstand voltage: 6 kV
  • Pollution degree: 3
  • Overvoltage category: IV
  • Dimensions (H x L x W): 85mm x 78.5mm x 36mm
  • Weight: 0.25 kg
Key Features
  • 2P, 1A, D curve, 6000A breaking capacity
  • Thermal-magnetic trip unit technology
  • Clip-on mounting mode for easy installation
  • Trip indicator for local signalling
  • IP20 rated for protection against solid objects
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Residential: Homes, apartments, offices
  • Commercial: Retail, hospitality, workspaces
  • General: Any location requiring circuit protection
Standards & Compliance
  • Complies with EN/IEC 60898-1 and EN/IEC 60947-2 for safety and performance standards.
Environmental Benefits
  • Compliant with RoHS directive, ensuring reduced environmental impact.
Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The Acti9 iC60N DISBO Miniature Circuit Breaker is available now for immediate purchase. Ideal for residential and commercial applications requiring reliable circuit protection.

A9F45201 (A9F45201, 234 Kb) [Download]
