MCB UL1077 10kA 3P+N 16A C Curve Miniature Circuit Breaker UL1077 Certified by Allen-Bradley
The MCB UL1077 10kA 3P+N 16A C Curve is a reliable miniature circuit breaker designed for industrial, commercial, and residential applications. With a breaking capacity of 10kA and a C Curve trip characteristic, it effectively protects circuits from overloads and short circuits. This UL1077 certified device ensures safety and compliance, making it an essential component for any electrical panel.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Miniature Circuit Breaker 16A C Curve, 3P+N MCB, UL1077 Circuit Breaker
Technical Specifications
- Standard: UL1077
- Breaking Capacity: 10kA
- Poles: 3P+N
- Current Rating: 16A
- Trip Curve: C Curve
- Voltage Rating: Typically up to 415V AC
- Dimensions (H x L x W): 85mm x 60mm x 70mm
- Weight: 0.3 kg
Key Features
- Miniature Circuit Breaker (MCB) with UL1077 certification
- Rated breaking capacity of 10kA
- 3 Pole plus Neutral configuration
- 16 Ampere current rating
- C Curve trip characteristic for moderate inrush currents
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Industrial electrical panels
- Commercial electrical distribution
- Residential circuit protection
Standards & Compliance
- AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Helps prevent electrical fires and equipment damage, reducing waste and environmental hazards
- Supports energy efficiency by protecting circuits from overload
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The Allen-Bradley MCB UL1077 10kA 3P+N 16A C Curve is available for immediate purchase, ideal for protecting electrical circuits in industrial, commercial, and residential settings.
