MCCB 140G H Frame 36kA 4P 160A Electronic LSIG High Interrupting Capacity 4-Pole Design by Allen-Bradley
MCCB 140G H Frame 36kA 4P 160A Electronic LSIG is designed for robust electrical protection in industrial and commercial applications. With a high interrupting capacity of 36kA and a 4-pole design, it ensures comprehensive circuit safety. The electronic LSIG trip unit provides precise protection against overloads and faults, making it ideal for motor control centers and power panels.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Molded Case Circuit Breaker 140G, MCCB 160A 4P, Electronic LSIG Breaker
Technical Specifications
- Rated Current: 160A
- Poles: 4
- Interrupting Capacity: 36kA
- Trip Unit Type: Electronic LSIG
- Frame Size: H
- Breaking Capacity: 36kA at 415V AC
- Dimensions (H x L x W): 200mm x 120mm x 150mm
- Weight: 5 kg
Key Features
- High interrupting capacity of 36kA for enhanced safety
- 4-pole design for comprehensive circuit protection
- Electronic LSIG (Long-time, Short-time, Instantaneous, Ground fault) trip unit for precise protection
- H Frame size suitable for high current applications
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards.
Applications
- Industrial electrical distribution systems
- Commercial building electrical protection
- Motor control centers
- Power panels requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Electronic trip unit improves energy efficiency by reducing nuisance trips
- Durable design reduces waste and replacement frequency
Warranty Information
1 year manufacturer warranty covering defects in materials and workmanship.
Available Now
The Allen-Bradley MCCB 140G H Frame 36kA 4P 160A Electronic LSIG is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
