MCCB 140G H FRAME 36kA 4P 25A Electronic LSIG 4-Pole Design High Interrupting Capacity Compact Installation by Allen-Bradley
MCCB 140G H FRAME 36kA 4P 25A Electronic LSIG is a robust molded case circuit breaker designed for industrial and commercial electrical protection. With a high interrupting capacity of 36kA and an electronic LSIG trip unit, it ensures reliable performance in electrical distribution panels and motor control centers. Ideal for licensed electricians, this breaker enhances safety and efficiency in electrical systems.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Alternatively Known As: Molded Case Circuit Breaker 25A, MCCB 4P 36kA, Electronic Trip Circuit Breaker
Technical Specifications
- Poles: 4
- Rated Current: 25A
- Interrupting Capacity: 36kA
- Trip Unit: Electronic LSIG
- Frame Size: H
- Type: Molded Case Circuit Breaker
- Dimensions (H x L x W): 150mm x 85mm x 100mm
- Weight: 3.5 kg
Key Features
- 4-pole molded case circuit breaker
- Electronic LSIG (Long-time, Short-time, Instantaneous, Ground-fault) trip unit
- High interrupting capacity of 36kA
- Rated current of 25A
- H frame size for compact installation
Professional Installation Requirements
- Installation must be performed by a licensed electrician to ensure compliance with electrical safety standards and proper operation.
Applications
- Industrial electrical distribution panels
- Commercial building electrical protection
- Motor control centers
- Electrical safety and overload protection
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Enhances electrical safety reducing risk of fire and equipment damage
- Supports energy efficiency by preventing electrical faults and downtime
Warranty Information
1 year limited warranty covering manufacturing defects.
Available Now
The Allen-Bradley MCCB 140G H FRAME 36kA 4P 25A Electronic LSIG is available for immediate purchase, ideal for industrial and commercial electrical protection applications.
