MCCB 70kA 4P 63A | Fixed Thermal Magnetic | 690V by NHP

BRAND: NHP
SKU: 140GG6C4C63
$888.60 List price: $1,180.00
+ −
30 Days Return Delivery Options
MCCB with 70kA breaking capacity and 4 poles—ideal for industrial and commercial power distribution. Built for reliable circuit protection, with fixed thermal magnetic trip and 690V operation.

Product Name/Title: Allen-Bradley 140G MCCB G Frame 70kA 4P 63A Fixed Thermal Magnetic

Brand: NHP

SKU: 140GG6C4C63

Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Circuit Breaker 63A, Thermal Magnetic Circuit Breaker

Technical Specifications
  • Rated Current: 63 A
  • Number of Poles: 4
  • Max Rated Operation Voltage: 690 V
  • Rated Ultimate Short Circuit Breaking Capacity: 70 kA
  • Rated Service Short Circuit Breaking Capacity: 35 kA
  • Type of Protection: Thermal/magnetic release
  • Trip Curve: Fixed thermal, fixed magnetic
  • Frame Size Rating: 160 A
  • Rated Frequency: 50-60 Hz
  • Rated Insulation Voltage: 800 V
  • Rated Short Circuit Breaking Capacity (ICU): 10 kA at 690 V AC
  • Rated Short Circuit Breaking Capacity (ICS): 5 kA at 690 V AC
  • Rated Impulse Withstand Voltage: 8 kV
  • Electrical Life: 8000 cycles
  • Mechanical Life: 25000 cycles
  • Power Loss: 17.2 W
  • Suitable for Isolation: Yes
  • Dimensions (H x L x W): 130mm x 70mm x 101.2mm
  • Weight: 1.4 kg
Key Features
  • Fixed thermal and magnetic trip unit for reliable protection.
  • Rated short circuit breaking capacity of 70 kA at 415 V.
  • Suitable for isolation and reverse connection of supply.
Professional Installation Requirements
  • Professional installation by a qualified electrician is recommended for optimal safety.
Applications
  • Industrial: Power distribution and protection in manufacturing facilities
  • Commercial: Electrical systems in commercial buildings
  • General: Any application requiring reliable circuit protection
Standards & Compliance
  • Complies with relevant Australian standards for electrical safety.
Environmental Benefits
  • Designed for high performance and reliability, reducing the risk of electrical failures.
Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The Allen-Bradley 140G MCCB G Frame 70kA 4P 63A Fixed Thermal Magnetic is available now for immediate purchase. Ideal for industrial and commercial electrical systems.

Non-Returnable & Non-Cancellable

140GG6C4C63-AU-140G-MCCB-G-Frame-Datasheet.pdf (140GG6C4C63-AU-140G-MCCB-G-Frame-Datasheet.pdf, 276 Kb) [Download]
