Allen-Bradley 140G MCCB H Frame 50kA 3P 160A Electronic LSI

MCCB H Frame 50kA 3P 160A | Electronic LSI | High Breaking Capacity by NHP

BRAND: NHP

SKU: 140GH3H3D16

$1,948.60 List price: $2,587.50

+ −

30 Days Return Delivery Options

MCCB H Frame with 50kA breaking capacity and electronic LSI—ideal for industrial motor control and commercial power distribution. Built for precise protection, with high efficiency and reliability.

Description
Attachments

Product Name/Title: Allen-Bradley 140G MCCB H Frame 50kA 3P 160A Electronic LSI

Brand: NHP

SKU: 140GH3H3D16

Alternatively Known As: Moulded Case Circuit Breaker, MCCB, Circuit Breaker 160A

Technical Specifications

Rated Current: 160 A
Number of Poles: 3
Max Rated Operation Voltage: 690 V
Rated Ultimate Short Circuit Breaking Capacity: 50 kA
Rated Service Short Circuit Breaking Capacity: 50 kA
Type of Protection Trip Unit: Electronic release
Trip Curve: LSI
Long Time Overload Protection Adjustment Range: 64-160 A
Instantaneous Protection Adjustment Range: 160-1600 A
Rated Frequency: 50-60 Hz
Rated Insulation Voltage: 1000 V
Rated Short Circuit Breaking Capacity (ICU): 12 kA
Rated Short Circuit Breaking Capacity (ICS): 12 kA
Rated Impulse Withstand Voltage: 8 kV
Electrical Life: 8000 cycles
Mechanical Life: 25000 cycles
Power Loss: 25.4 W
Dimensions (H x L x W): 130mm x 116mm x 90mm
Weight: 1.2 kg

Key Features

Electronic release trip unit for precise protection.
High breaking capacity of 50 kA.
Suitable for isolation.

Professional Installation Requirements

Professional installation by a qualified electrician is recommended for optimal safety.

Applications

Industrial: Motor control and protection
Commercial: Power distribution systems

Standards & Compliance

Complies with relevant Australian standards for electrical safety.

Environmental Benefits

Designed for high efficiency and reliability in power management.

Warranty Information

Standard warranty as per manufacturer guidelines.

Available Now

The Allen-Bradley 140G MCCB H Frame 50kA 3P 160A Electronic LSI is available now for immediate purchase. Ideal for industrial and commercial power distribution applications.

Non-Returnable & Non-Cancellable

140GH3H3D16-AU-140G-MCCB-H-Frame-Datasheet.pdf (140GH3H3D16-AU-140G-MCCB-H-Frame-Datasheet.pdf, 275 Kb) [Download]
