MicroSD Memory Card Kit | Long Range Barcode Scanner | IP65 Rated | by SICK
The MicroSD Memory Card Kit is designed for long-range barcode scanning, featuring a side reading field of 105° and a fixed optical focus with a visible red laser light source. Ideal for industrial automation, logistics, and manufacturing, this robust scanner supports all current 1D barcode types and operates with a high scanning frequency of 400 Hz to 1000 Hz, ensuring efficient data capture and traceability.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Technical Specifications
- Reading field: Side (105°)
- Sensor type: Line scanner
- Optical focus: Fixed focus
- Light source: Visible red laser, 655 nm
- Laser class: Class 2, compliant with EN 60825-1:2014+A11:2021
- Aperture angle: ≤ 50°
- Reading distance: 25 mm to 330 mm
- Scanning frequency: 400 Hz to 1000 Hz
- Code resolution: 0.35 mm to 0.5 mm
- Connection types: 1 x POWER 5-pin M12 plug, 2 x PROFINET 4-pin M12 connectors
- Supply voltage: 10 V DC to 30 V DC
- Power consumption: 5 W
- Housing material: Aluminum die cast
- Window material: Glass
- Enclosure rating: IP65
- Protection class: III (VDE 0106/IEC 1010-1)
- MTBF: 100,000 hours
- MTTF (Laser diode): 40,000 hours
- Readable code structures: 1D codes including Code 39, Code 128, Code 93, Codabar, UPC/GTIN/EAN, Interleaved 2 of 5, Pharmacode
- Print ratio: 2:1 to 3:1
- Number of codes per scan: 1 to 10 (Standard decoder), 1 to 6 (SMART620)
- Number of codes per reading interval: 1 to 50 (auto-discriminating)
- Number of characters per reading interval: 1,500
- Number of multiple readings: 1 to 99
- Data transmission rate: 100 MBit/s full-duplex Ethernet
- Digital inputs: 2
- Digital outputs: 4
- Optical indicators: 5 LEDs
- Configuration software: SOPAS ET
- Dimensions (H x L x W): 38mm x 80mm x 96mm
- Weight: 0.31 kg
Key Features
- Long range barcode reading with side reading field of 105°
- Fixed optical focus with visible red laser light source (655 nm)
- High scanning frequency from 400 Hz to 1000 Hz
- Supports all current 1D barcode types including Code 39, Code 128, UPC, EAN
- Robust aluminum die cast housing with IP65 protection rating
- Multiple PROFINET interfaces with 2-port Ethernet switch
- MicroSD memory card included for data storage
- Complies with laser safety class 2 standards
Professional Installation Requirements
- Installation by qualified personnel with experience in industrial network and electrical systems is recommended to ensure proper setup and compliance with safety standards.
Applications
- Industrial automation for barcode reading
- Logistics and warehouse management
- Manufacturing process control
- Quality assurance and traceability
Standards & Compliance
- AS/NZS 60950 – Safety of IT and Communication Equipment
Environmental Benefits
- Durable design reduces need for frequent replacements, minimizing electronic waste
- Energy-efficient operation with low power consumption of 5 W
Warranty Information
Standard manufacturer warranty applies; please refer to SICK for specific warranty terms.
Available Now
The SICK CLV615-D2540 MicroSD Memory Card Kit is available for immediate purchase, ideal for industrial barcode scanning and automation applications.
