Miniature Circuit Breaker 50A | 6kA 1 Pole D Curve | IP40 by NHP
Miniature circuit breaker with 50A rated current and D curve—ideal for high inrush current applications. Built for residential, commercial, and industrial use, with 6kA short circuit capacity and IP40 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Miniature Circuit Breaker MCB 6kA 1 Pole 50A D Curve
Brand: NHP
SKU: DTM6150D
Alternatively Known As: Miniature Circuit Breaker, MCB, 50A Circuit Breaker, DIN Rail Circuit Breaker
Technical Specifications
- Rated Current: 50 A
- Number of Poles: 1
- Trip Curve: D
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: DC
- Rated Short Circuit Breaking Capacity: 6 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 0.75-35 mm²
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature: -25-55 °C
- Dimensions (H x L x W): 85mm x 75mm x 17.5mm
- Weight: 0.12 kg
Key Features
- Rated current of 50A with a D curve for high inrush current applications.
- 6kA short circuit breaking capacity for reliable protection.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, and small buildings
- Commercial: Offices and retail spaces
- Industrial: Machinery and equipment protection
Standards & Compliance
- Complies with AS/NZS 60898 and AS/NZS 60947 for safety and performance standards.
Environmental Benefits
- Efficient design reduces energy loss and enhances safety.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP DIN-T Miniature Circuit Breaker MCB 6kA 1 Pole 50A D Curve is available now for immediate purchase. Ideal for residential, commercial, and industrial applications.
