Miniature Circuit Breaker 6A 3Pole | 10kA C Curve | UL489 by NHP
Miniature circuit breaker with 6A rated current and C curve trip—ideal for industrial, commercial, and residential circuit protection. Built for safety, with 10kA short circuit capacity and UL489 compliance.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Allen-Bradley Miniature Circuit Breaker UL489 10kA 3Pole 6A C Curve
Brand: NHP
SKU: 1489M3C060
Alternatively Known As: MCB, Miniature Circuit Breaker, Circuit Protection Device
Technical Specifications
- Rated Current: 6 A
- Number of Poles: 3
- Trip Curve: C
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Rated Short Circuit Breaking Capacity: 10kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-35 mm² (solid), 1-25 mm² (multi-wired)
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -25-55 °C
- Dimensions (H x L x W): 111mm x 75mm x 52.5mm
- Weight: 0.38 kg
Key Features
- Rated current of 6A with a C curve trip characteristic.
- 3 poles for enhanced circuit protection.
- Rated short circuit breaking capacity of 10kA.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Industrial: Machinery and equipment protection
- Commercial: Electrical distribution systems
- Residential: Circuit protection in homes
Standards & Compliance
- Complies with AS/NZS 60947 for safety and performance standards.
Environmental Benefits
- Designed to minimize electrical hazards and enhance safety.
Warranty Information
Standard warranty as per manufacturer guidelines.
Available Now
The Allen-Bradley Miniature Circuit Breaker UL489 10kA 3Pole 6A C Curve is available now for immediate purchase. Ideal for industrial, commercial, and residential applications.
