Miniature Circuit Breaker 6kA 3 Pole | 6A C Curve | IP40 by NHP
Miniature circuit breaker with 6A rated current and C curve trip—ideal for residential, commercial, and industrial protection. Built for enhanced safety, with 6kA short circuit capacity and IP40 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP MOD6+ Miniature Circuit Breaker MCB 6kA 3 Pole 6A C Curve
Brand: NHP
SKU: MD6M306
Alternatively Known As: Miniature Circuit Breaker, MCB, Circuit Protection Device
Technical Specifications
- Rated Current: 6 A
- Number of Poles: 3
- Trip Curve: C
- Rated Voltage: 415 V
- Frequency: 50-60 Hz
- Voltage Type: AC
- Rated Short Circuit Breaking Capacity: 6 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 0.75-25 mm² (solid core), 0.75-16 mm² (multi-wired)
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 4 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Operating Ambient Temperature: -25 to 70 °C
- Dimensions (H x L x W): 85mm x 75.8mm x 52.5mm
- Weight: 0.35 kg
Key Features
- Rated current of 6A with a C curve trip characteristic.
- Three poles for enhanced circuit protection.
- Rated short circuit breaking capacity of 6kA.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes and apartments
- Commercial: Offices and retail spaces
- Industrial: Machinery and equipment protection
Standards & Compliance
- Complies with AS/NZS 60898 for circuit breakers.
Environmental Benefits
- Enhances electrical safety, reducing the risk of fire hazards.
Warranty Information
1 year warranty against manufacturing defects.
Available Now
The NHP MOD6+ Miniature Circuit Breaker MCB 6kA 3 Pole 6A C Curve is available now for immediate purchase, ideal for ensuring electrical safety in various applications.
