Miniature Circuit Breaker DC 6kA 1Pole 50A | C Curve | IP40 by NHP
Miniature circuit breaker with 50A rated current and C curve trip—ideal for residential and commercial electrical installations. Built for safety and reliability, with 6kA short circuit capacity and IP40 protection.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: NHP DIN-T Miniature Circuit Breaker DC 6kA 1Pole 50A C Curve
Brand: NHP
SKU: DTCBDC150C
Alternatively Known As: Miniature Circuit Breaker, MCB, DC Circuit Breaker
Technical Specifications
- Rated Current: 50 A
- Number of Poles: 1
- Trip Curve: C
- Rated Voltage: 240 V
- Frequency: 50-60 Hz
- Voltage Type: AC/DC
- Rated Short Circuit Breaking Capacity: 6 kA
- Degree of Protection: IP40
- Connectable Conductor Cross Section: 1-35 mm² (solid core), 1-25 mm² (multi-wired)
- Rated Insulation Voltage: 440 V
- Rated Impulse Withstand Voltage: 6 kV
- Pollution Degree: 3
- Rated Surrounding Temperature: 30 °C
- Ambient Temperature During Operating: -25-70 °C
- Dimensions (H x L x W): 86mm x 76mm x 18mm
- Weight: 0.13 kg
Key Features
- Rated current of 50A with a C curve trip characteristic.
- 6kA short circuit breaking capacity.
- Suitable for both AC and DC applications.
Professional Installation Requirements
- Professional installation by a qualified electrician is recommended for optimal safety.
Applications
- Residential: Homes, apartments, offices
- Commercial: Retail, hospitality, workspaces
- General: Any electrical installation requiring circuit protection
Standards & Compliance
- Complies with AS/NZS 60898 for safety and performance standards.
Environmental Benefits
- Designed to enhance safety and reliability in electrical systems.
Warranty Information
Standard warranty applies.
Available Now
The NHP DIN-T Miniature Circuit Breaker DC 6kA 1Pole 50A C Curve is available now for immediate purchase. Ideal for residential and commercial electrical installations.
