Modular Contactor 18mm 20A 230VAC 1NO+1NC Eltech

BRAND: Eltech
SKU: WMC120230V11
$54.80 List price: $73.10
+ −
30 Days Return Electricians Unlock Trade Access
Eltech modular contactor features 20A rating, 230VAC coil and 1NO+1NC contacts in 18mm module. Ideal for switchboard load switching.

Alternatively Known As: Eltech 18mm Contactor, Eltech WMC120230V11

Technical Specifications
  • Current Rating: 20A
  • Voltage Rating: 230VAC
  • Width: 18mm
  • Contact Configuration: 1NO+1NC
  • Model: WMC120230V11
  • Dimensions (H x L x W): 90mm x 65mm x 18mm
  • Weight: 0.1 kg
Key Features
  • Compact 18mm module width
  • Efficient load switching with 20A capacity
  • 230VAC coil for energy efficiency
  • 1 Normally Open and 1 Normally Closed contact configuration
Professional Installation Requirements
  • Installation must be performed by a qualified electrician in accordance with local electrical standards and regulations.
Applications
  • Residential and commercial switchboards
  • Load switching in automation systems
  • Lighting control systems
Standards & Compliance
  • AS/NZS 60947
Environmental Benefits
  • Contributes to efficient energy distribution systems
Warranty Information

Eltech general warranty applies; contact for specific details.

Available Now

Available through authorised Australian distributors.
