Modular Contactor 36mm 25A 230VAC 4NC Eltech

BRAND: Eltech
SKU: WMC125230V04
$68.60 List price: $91.40
+ −
30 Days Return Electricians Unlock Trade Access
Eltech modular contactor features 25A rating, 230VAC coil and 4NC contacts in 36mm module. Ideal for switchboard load switching.

Alternatively Known As: Eltech WMC‑125‑230V‑04 Modular Contactor

Technical Specifications
  • Rated Operational Current (AC1): 25 A
  • Coil Voltage: 230 VAC
  • Contact Configuration: 4 × Normally‑Closed (NC) contacts
  • Module Width: 36 mm (2 modules)
  • Protection Class: IP20
  • Ambient Operating Temperature: −5 °C to 55 °C
  • Rated Insulation Voltage (Ui): 500 V
  • Rated Impulse Withstand Voltage (Uimp): 4 kV
  • Mechanical Endurance: 3 000 000 switching cycles
  • Electrical Endurance: 250 000 switching cycles
  • Coil Inrush Duration: 10 – 40 ms
  • Opening Delay: < 20 ms (for 20 A & 25 A variants)
  • Terminal Capacity – Main Contact: Stranded 1–6 mm²; Solid 1–10 mm²
  • Terminal Capacity – Coil: 1–2.5 mm²
  • Screw Torque – Main Contact: 1.2 Nm
  • Screw Torque – Coil Terminal: 0.6 Nm
  • Dimensions (H x L x W): 80mm x 65mm x 36mm
  • Weight: 0.2 kg
Key Features
  • Compact 36 mm DIN‑rail modular width for space‑sensitive installations
  • High durability with 3 million mechanical and 250 000 electrical cycles
  • Fast response with < 20 ms opening delay
  • High dielectric withstand (4 kV impulse rating) and IP20 protection
  • Broad ambient operation from −5 °C to 55 °C
Professional Installation Requirements
  • Installation must be performed by a qualified electrician to ensure compliance with Australian wiring standards.
Applications
  • Lighting control circuits in residential and commercial switchboards
  • Switching of small EC motors and inductive loads
  • Power distribution and automation control panels
Standards & Compliance
  • Complies with AS/NZS 3000 Wiring Rules (as a DIN‑rail modular contactor in switchboards)
Environmental Benefits
  • Compact DIN‑rail design reduces material usage and installation space
  • Durable construction reduces replacement frequency and waste
Warranty Information

1 year manufacturer's warranty against manufacturing defects.

Available Now

Available through authorised Australian distributors and online; contact SCHNAP for current stock and lead times.
