Modular Contactor 54mm 63A 230VAC 4NC Eltech

BRAND: Eltech
SKU: WMC163230V04
$171.70 List price: $228.90
+ −
30 Days Return Electricians Unlock Trade Access
Eltech modular contactor features 63A rating, 230VAC coil and 4NC contacts in 54mm module. Ideal for switchboard load switching.

Alternatively Known As: Modular Contactor 54 mm 63 A 230 VAC 4 NC

Technical Specifications
  • Rated Thermal Current (Ith): 63 A
  • Coil Voltage: 230 VAC
  • Contacts: 4 × Normally Closed (NC)
  • Modules Width: 3 modules (54 mm)
  • Rated Insulation Voltage (Ui): 500 V
  • Rated Frequency: 50/60 Hz
  • Impulse Withstand Voltage (Uimp): 4 kV
  • Mechanical Endurance: 3 000 000 switching cycles
  • Electrical Endurance: 250 000 switching cycles
  • Ambient Operating Temperature: −5 °C to 55 °C
  • Protection Class: IP20
  • Dimensions (H x L x W): 90mm x 54mm x 54mm
  • Weight: 0.2 kg
Key Features
  • Compact DIN‑modular form factor (54 mm width)
  • High endurance with 3 million mechanical and 250 000 electrical switching cycles
  • Robust insulation and impulse voltage withstand for switchboard environments
  • Low‑heat dissipation design for extended lifespan
  • Suitable for lighting control and small EC motor switching in distribution boards
Applications
  • Switchboard load switching in residential, commercial and light‑industrial panels
  • Lighting control circuits
  • Control of small electronically commutated (EC) motors
Standards & Compliance
  • IEC 61095
  • IEC 60947‑4‑1
Environmental Benefits
  • Low heat dissipation reduces energy loss and extends product lifespan
Warranty Information

Standard Eltech 7‑Year Warranty when installed by a licensed electrician per Eltech conditions

Available Now

Available through authorised Australian distributors
