Molded Case Circuit Breaker 63A 25kA 415VAC | 3P3D Configuration | Thermal-Magnetic Trip | by Clipsal
The Molded Case Circuit Breaker 63A 25kA 415VAC is designed for reliable protection in commercial and industrial electrical systems. Featuring a robust 3P3D configuration and thermal-magnetic trip unit, it ensures overload and short-circuit protection. Ideal for installation in distribution boards and switchboards, this breaker complies with international safety standards, making it a dependable choice for licensed electricians.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Molded Case Circuit Breaker 63A 25kA 415VAC | 3P3D Configuration | Thermal-Magnetic Trip | by Clipsal
Brand: Clipsal
SKU: SCHLV510305
Alternatively Known As: Clipsal CVS100B Circuit Breaker, 63A 3 Pole MCCB, SCHLV510305, 3P3D 63A Breaker, Clipsal MCCB 63A
Technical Specifications
- Type: Molded Case Circuit Breaker (MCCB)
- Poles: 3P3D (Three Pole, Three Direct)
- Rated Current: 63A
- Breaking Capacity: 25kA at 415VAC
- Voltage Rating: 415VAC
- Trip Unit: Thermal-Magnetic (TM63D)
- Standards: IEC 60947-2, AS/NZS 60947.2
- Mounting: DIN rail or panel mount
- Operating Temperature: -25°C to +70°C
- Dimensions (H x L x W): 130mm x 75mm x 105mm
- Weight: 2.5 kg
Key Features
- 3 pole, 3 direct (3P3D) configuration for three-phase systems
- Rated current: 63A
- Breaking capacity: 25kA at 415VAC
- Thermal-magnetic trip unit (TM63D) for overload and short-circuit protection
- Robust and compact design for easy installation
- Complies with international and Australian safety standards
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Commercial and industrial electrical distribution boards
- Main and sub-main circuit protection
- Switchboards in factories, warehouses, and large buildings
Standards & Compliance
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
- Complies with AS/NZS 60947.2 – Low-voltage switchgear and controlgear
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and equipment damage
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal CVS100B TM63D 3P3D 63A 25kA 415VAC Circuit Breaker (SCHLV510305) is available for immediate purchase. Ideal for commercial and industrial electrical protection applications.
