Motor Circuit Breaker 30-40A | Thermal-Magnetic Protection | 3-Pole Configuration | by Clipsal
The Motor Circuit Breaker 30-40A is designed for reliable motor protection in industrial and commercial applications. Featuring thermal-magnetic protection and an adjustable current range, this 3-pole breaker ensures safety and efficiency in machinery control panels and HVAC systems. With a robust design and manual ON/OFF operation, it’s perfect for licensed electricians looking to enhance electrical safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Motor Circuit Breaker 30-40A | Thermal-Magnetic Protection | 3-Pole Configuration | by Clipsal
Brand: Clipsal
SKU: SCHGV3P40
Alternatively Known As: Motor Circuit Breaker 30-40A, Thermal Magnetic Breaker, 3 Pole Motor Breaker, SCHGV3P40, Clipsal Motor Protection Switch
Technical Specifications
- Type: Motor Circuit Breaker
- Protection: Thermal-magnetic
- Current Range: 30-40A adjustable
- Poles: 3
- Rated Voltage: 690V AC
- Breaking Capacity: 50kA at 400V
- Trip Class: 10
- Mounting: DIN rail
- Standards: IEC/EN 60947-2, IEC/EN 60947-4-1
- Dimensions (H x L x W): 90mm x 80mm x 55mm
- Weight: 0.7 kg
Key Features
- Thermal-magnetic protection for motors
- Adjustable current range: 30-40A
- 3-pole configuration
- Robust design for industrial environments
- Manual ON/OFF operation
- Trip indication for fault detection
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local electrical regulations.
Applications
- Industrial motor protection
- Commercial electrical panels
- Machinery control panels
- Pump and HVAC systems
Standards & Compliance
- Complies with AS/NZS 60950 – Safety of IT and Communication Equipment
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Prevents electrical faults, reducing risk of equipment damage and waste
- Enhances energy efficiency by protecting motors from overload
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal SCHGV3P40 Motor Circuit Breaker 30-40A is available for immediate purchase. Ideal for industrial and commercial motor protection applications.
