Moulded Case Circuit Breaker NSX100H 3P 100A 36kA Clipsal

BRAND: Clipsal
SKU: SCHBLV429670/29680
$12,051.50 List price: $15,018.10
+ −
30 Days Return Electricians Unlock Trade Access
Clipsal Moulded Case Circuit Breaker 3P 100A features 36kA breaking capacity. Suited to main switchboards and sub-mains.

Product Name/Title: BTS NSX100H TM100D Circuit Breaker | 100A Rated Current | 36kA Breaking Capacity | 3P/4P Configuration | @Each of 1 | by Clipsal

Brand: Clipsal

SKU: SCHBLV429670/29680

Alternatively Known As: NSX100H Circuit Breaker, Schneider NSX100H, 3P/4P MCCB, TM100D MCCB, NSX100H 100A Breaker

Technical Specifications
  • Rated current: 100A
  • Number of poles: 3P/4P
  • Breaking capacity: 36kA at 415V AC
  • Trip unit: TM100D (thermal-magnetic)
  • Rated insulation voltage: 690V
  • Utilization category: A
  • Frequency: 50/60Hz
  • Standard compliance: IEC 60947-2
  • Dimensions (H x L x W): 161mm x 86mm x 105mm
  • Weight: 2.5 kg
Key Features
  • 3-pole or 4-pole configuration for flexible installation
  • Rated current: 100A
  • Breaking capacity: 36kA at 415V AC
  • Thermal-magnetic trip unit (TM100D) for reliable protection
  • Compact NSX design for space-saving panel integration
  • High performance and durability
Professional Installation Requirements
  • Installation must be performed by a licensed electrician in accordance with Australian standards and local regulations.
Applications
  • Commercial and industrial electrical distribution systems
  • Panel boards and switchboards
  • Protection of electrical circuits against overloads and short circuits
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
  • Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
  • Supports efficient energy management by preventing electrical faults
  • Long operational life reduces replacement frequency and waste
Warranty Information

12 months manufacturer's warranty against defects.

Available Now

The Clipsal BTS NSX100H TM100D 3P/4P 240VA Circuit Breaker (SCHBLV429670/29680) is available for immediate purchase. Ideal for commercial and industrial electrical distribution systems.
