Moulded Case Circuit Breaker NSX100H 3P 100A 36kA Fixed Type Clipsal

BRAND: Clipsal
SKU: SCHBLV429671/29681
$12,051.50 List price: $15,018.10
+ −
30 Days Return Electricians Unlock Trade Access
Clipsal Moulded Case Circuit Breaker 3P 100A features 36kA breaking capacity, 240VAC rated. Suited to main switchboards and sub-mains.

Product Name/Title: Molded Case Circuit Breaker BTS NSX100H TM80D | 3P/4P Configuration | 100A Rated | 240VAC Operation | @Each of 1 | by Clipsal

Brand: Clipsal

SKU: SCHBLV429671/29681

Alternatively Known As: NSX100H Circuit Breaker, Schneider NSX100H, TM80D MCCB, 3 Pole 4 Pole MCCB, NSX100H 100A Breaker

Technical Specifications
  • Type: Molded Case Circuit Breaker (MCCB)
  • Poles: 3P/4P
  • Rated Current: 100A
  • Trip Unit: TM80D (Thermal-Magnetic)
  • Rated Voltage: 240VAC
  • Breaking Capacity: 36kA at 415V AC
  • Standards: IEC 60947-2
  • Mounting: Fixed
  • Frequency: 50/60Hz
  • Dimensions (H x L x W): 161mm x 86mm x 105mm
  • Weight: 2.5 kg
Key Features
  • Thermal-magnetic circuit breaker for reliable circuit protection
  • 3-pole or 4-pole configuration for flexible installation
  • Rated for 100A with TM80D trip unit
  • Suitable for 240VAC operation
  • Compact NSX design for space-saving panel integration
  • High breaking capacity for enhanced safety
Professional Installation Requirements
  • Installation must be performed by a licensed electrician in accordance with local wiring rules and standards.
Applications
  • Commercial and industrial electrical distribution systems
  • Panel boards and switchboards
  • Protection of circuits against overloads and short circuits
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
  • Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
  • Designed for long operational life, reducing replacement frequency and waste
  • High efficiency reduces energy losses in electrical distribution
Warranty Information

12 months manufacturer's warranty against defects.

Available Now

The Clipsal BTS NSX100H TM80D 3P/4P 240VAC Circuit Breaker (SCHBLV429671/29681) is available for immediate purchase. Ideal for commercial and industrial electrical distribution systems.
