Moulded Case Circuit Breaker NSX100H 4P 100A 36kA 240VAC Clipsal
Clipsal Moulded Case Circuit Breaker 4P 100A features 36kA breaking capacity, 240VAC rated. Suited to main switchboards and sub-mains.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Molded Case Circuit Breaker NSX100H TM100D | 100A Rated | 4P/3P Configurable | 240V AC | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHBLV429680/29670
Alternatively Known As: NSX100H Circuit Breaker, Schneider NSX100H, TM100D MCCB, 4 Pole MCCB, 3 Pole MCCB, Molded Case Circuit Breaker 100A
Technical Specifications
- Type: Molded Case Circuit Breaker (MCCB)
- Rated Current: 100A
- Poles: 4P/3P configurable
- Trip Unit: TM100D (Thermal-Magnetic)
- Rated Voltage: 240V AC
- Breaking Capacity: 36kA at 415V AC
- Standards: IEC 60947-2 compliant
- Mounting: Fixed
- Frequency: 50/60Hz
- Dimensions (H x L x W): 161mm x 86mm x 105mm
- Weight: 2.5 kg
Key Features
- High-performance molded case circuit breaker
- 4-pole/3-pole configuration for flexible installation
- Thermal-magnetic trip unit (TM100D) for reliable protection
- Rated operational voltage: 240V AC
- Compact design for easy integration into panels
- Robust construction for demanding environments
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with local regulations and standards.
Applications
- Commercial and industrial electrical distribution systems
- Panel boards and switchboards
- Protection of electrical circuits against overloads and short circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and equipment damage
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal BTS NSX100H TM100D 4P/3P 240VA Circuit Breaker (SCHBLV429680/29670) is available for immediate purchase. Ideal for commercial and industrial electrical distribution systems.
