Moulded Case Circuit Breaker NSX100N 4P 63A 36kA 240VAC Clipsal

BRAND: Clipsal
SKU: SCHBLV429852/29842
$10,935.60 List price: $13,627.50
+ −
30 Days Return Electricians Unlock Trade Access
Clipsal Moulded Case Circuit Breaker 4P 63A features 36kA breaking capacity, 240VAC rated. Suited to main switchboards and sub-mains.

Product Name/Title: Molded Case Circuit Breaker NSX100N TM63D | 4P/3P Configuration | 63A Rated Current | 240VAC | @Each of 1 | by Clipsal

Brand: Clipsal

SKU: SCHBLV429852/29842

Alternatively Known As: NSX100N Circuit Breaker, Schneider NSX100N, 4 Pole MCCB, 3 Pole MCCB, TM63D MCCB, NSX100N TM63D, MCCB 100A, NSX100N 240VAC

Technical Specifications
  • Type: Molded Case Circuit Breaker (MCCB)
  • Frame: NSX100N
  • Rated Current: 63A (TM63D trip unit)
  • Poles: 4P/3P
  • Rated Voltage: 240VAC
  • Breaking Capacity: 36kA at 415V AC
  • Trip Unit: Thermal-magnetic (TM-D)
  • Standards: IEC 60947-2
  • Mounting: Fixed
  • Terminal Type: Front connection
  • Dimensions (H x L x W): 161mm x 86mm x 105mm
  • Weight: 2.5 kg
Key Features
  • Thermal-magnetic circuit breaker for reliable protection
  • 4-pole/3-pole configuration for flexible installation
  • Rated for 240VAC operation
  • High breaking capacity for enhanced safety
  • Compact NSX100N frame for space-saving installation
  • Adjustable thermal and magnetic trip settings
Professional Installation Requirements
  • Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
  • Commercial and industrial electrical distribution systems
  • Main and sub-main switchboards
  • Protection of electrical circuits against overload and short-circuit
  • Suitable for use in buildings, factories, and infrastructure projects
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
  • Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
  • Designed for long service life, reducing replacement frequency and waste
  • Compliant with RoHS for reduced hazardous substances
  • Supports energy-efficient electrical distribution
Warranty Information

12 months manufacturer's warranty against defects.

Available Now

The Clipsal BTS NSX100N TM63D 4P/3P 240VAC Circuit Breaker (SCHBLV429852/29842) is available for immediate purchase. Ideal for commercial and industrial electrical protection applications.
