Moulded Case Circuit Breaker NSX100N 4P 63A 36kA Fixed Type Clipsal
Clipsal Moulded Case Circuit Breaker 4P 63A features 36kA breaking capacity, 240VAC rated. Suited to main switchboards and sub-mains.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: BTS NSX100N TM63D 4P Circuit Breaker | 63A Rated Current | 36kA Breaking Capacity | 240VAC | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHBLV429852/29852
Alternatively Known As: NSX100N 4 Pole Circuit Breaker, Schneider NSX100N TM63D, 100A MCCB, 4P MCCB, NSX100N MCCB, SCHBLV429852, SCHBLV29852
Technical Specifications
- Rated current: 63A
- Number of poles: 4
- Rated operational voltage: 240VAC (also suitable for 415VAC applications)
- Breaking capacity: 36kA at 415V AC
- Trip unit: Thermal-magnetic (TM63D)
- Frame size: NSX100N
- Conforms to IEC 60947-2
- Mounting: Fixed
- Frequency: 50/60Hz
- Dimensions (H x L x W): 161mm x 86mm x 140mm
- Weight: 2.5 kg
Key Features
- 4 pole circuit breaker for three-phase and neutral protection
- Rated operational voltage: 240VAC
- Thermal-magnetic trip unit (TM63D) for reliable overload and short-circuit protection
- Breaking capacity: 36kA at 415V AC
- Compact NSX100N frame for space-saving installation
- Complies with IEC 60947-2 standards
- High performance and reliability for demanding applications
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution systems
- Main and sub-main switchboards
- Protection of electrical circuits against overloads and short circuits
- Suitable for use in infrastructure, manufacturing, and large facilities
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
- Enables safe and efficient electrical distribution, reducing risk of electrical fires and equipment damage.
- Long operational life reduces replacement frequency and associated waste.
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal BTS NSX100N TM63D 4P/4P 240VAC circuit breaker (SCHBLV429852/29852) is available for immediate purchase. Ideal for commercial and industrial switchboard applications requiring reliable circuit protection.
