Moulded Case Circuit Breaker NSX100N 4P 80A 36kA 240VAC Clipsal
Clipsal Moulded Case Circuit Breaker 4P 80A features 36kA breaking capacity, 240VAC rated. Suited to main switchboards and sub-mains.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Molded Case Circuit Breaker NSX100N TM80D | 80A Rated Current | 4P/3P Configuration | 240VAC | @Each of 1 | by Clipsal
Brand: Clipsal
SKU: SCHBLV429851/29841
Alternatively Known As: NSX100N Circuit Breaker, Schneider NSX100N, TM80D MCCB, 4 Pole MCCB, 3 Pole MCCB, NSX100N 240V Breaker
Technical Specifications
- Type: Molded Case Circuit Breaker (MCCB)
- Rated Current: 80A (TM80D trip unit)
- Poles: 4P/3P
- Rated Operational Voltage: 240VAC
- Breaking Capacity: 36kA at 415V AC
- Trip Unit: Thermal-magnetic (TM80D)
- Mounting: Fixed
- Standards: IEC 60947-2, AS/NZS 60947.2
- Dimensions (H x L x W): 161mm x 86mm x 105mm
- Weight: 2.5 kg
Key Features
- Compact molded case circuit breaker for reliable protection
- Adjustable thermal-magnetic trip unit (TM80D)
- Available in 4-pole and 3-pole configurations
- Rated operational voltage: 240VAC
- High breaking capacity for enhanced safety
- Complies with international and Australian standards
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 and local regulations.
Applications
- Commercial and industrial electrical distribution systems
- Main and sub-main circuit protection
- Switchboards and panel boards
- Protection of electrical installations against overloads and short circuits
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
- Complies with AS/NZS 60947.2 – Low-voltage switchgear and controlgear
Environmental Benefits
- Supports energy efficiency by minimizing electrical losses and improving system reliability
- Long operational life reduces replacement frequency and waste
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal BTS NSX100N TM80D 4P/3P 240VAC Circuit Breaker (SCHBLV429851/29841) is available for immediate purchase. Ideal for commercial and industrial electrical distribution systems.
