Moulded Case Circuit Breaker NSX160N 3P 160A 36kA 415VAC Clipsal

BRAND: Clipsal
SKU: SCHBLV430840/30840
$12,539.70 List price: $15,626.40
+ −
30 Days Return Electricians Unlock Trade Access
Clipsal Moulded Case Circuit Breaker 3P 160A features 36kA breaking capacity, 415VAC rated. Suited to main switchboards and sub-mains.

Product Name/Title: Molded Case Circuit Breaker NSX160N TM160D | 3-Pole 160A | 36kA Breaking Capacity | by Clipsal

Brand: Clipsal

SKU: SCHBLV430840/30840

Alternatively Known As: NSX160N Circuit Breaker, Schneider NSX160N, 160A 3P MCCB, NSX160N TM160D, MCCB 3 Pole 160A

Technical Specifications
  • Type: Molded Case Circuit Breaker (MCCB)
  • Poles: 3P (Three Pole)
  • Rated Current: 160A
  • Breaking Capacity: 36kA at 415V AC
  • Trip Unit: TM160D (Thermal Magnetic)
  • Rated Insulation Voltage: 690V AC
  • Rated Operational Voltage: 415V AC
  • Frequency: 50/60Hz
  • Utilization Category: A
  • Conformity: IEC 60947-2
  • Dimensions (H x L x W): 161mm x 86mm x 105mm
  • Weight: 3.5 kg
Key Features
  • 3-pole circuit breaker with thermal-magnetic protection
  • Rated current: 160A
  • Breaking capacity: 36kA at 415V AC
  • Adjustable thermal and magnetic trip units
  • Compact NSX design for space-saving installation
  • High reliability and robust construction
Professional Installation Requirements
  • Installation must be performed by a licensed electrician in accordance with local regulations and standards.
Applications
  • Commercial and industrial electrical distribution systems
  • Main and sub-main switchboards
  • Protection of electrical circuits against overloads and short circuits
  • Suitable for use in infrastructure, manufacturing, and large facilities
Standards & Compliance
  • Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
  • Complies with AS/NZS 3820 – Essential Safety Requirements for Electrical Equipment
Environmental Benefits
  • Enables safe and efficient energy distribution, reducing risk of electrical fires and equipment damage.
  • Long operational life reduces replacement frequency and associated waste.
Warranty Information

12 months manufacturer's warranty against defects.

Available Now

The Clipsal BTS NSX160N TM160D 3P/3P 240VA Circuit Breaker (SCHBLV430840/30840) is available for immediate purchase. Ideal for commercial and industrial electrical distribution applications.
