Moulded Case Circuit Breaker NSX250H 4P 250A 36kA Fixed Type Clipsal
Clipsal Moulded Case Circuit Breaker 4P 250A features 36kA breaking capacity. Suited to main switchboards and sub-mains.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: BTS NSX250H TM250D 4P/4P Circuit Breaker | 250A Rated Current | 36kA Breaking Capacity | by Clipsal
Brand: Clipsal
SKU: SCHBLV431680/31680
Alternatively Known As: NSX250H Circuit Breaker, Schneider NSX250H, 250A MCCB, 4 Pole MCCB, SCHBLV431680/31680
Technical Specifications
- Rated current: 250A
- Number of poles: 4P/4P (4 protected poles)
- Trip unit: TM250D (Thermal-magnetic)
- Breaking capacity: 36kA at 415V AC
- Rated insulation voltage: 690V
- Utilization category: A
- Frequency: 50/60Hz
- Standards: IEC 60947-2, AS/NZS 60947.2
- Mounting: Fixed
- Terminal type: Front connection
- Dimensions (H x L x W): 255mm x 110mm x 140mm
- Weight: 5.5 kg
Key Features
- High-performance molded case circuit breaker (MCCB)
- Rated current: 250A
- 4 pole, 4 protected poles (4P/4P) configuration
- Thermal-magnetic trip unit (TM250D) for reliable protection
- Breaking capacity: 36kA at 415V AC
- Compact design for easy installation in switchboards
- Complies with international and Australian standards
Professional Installation Requirements
- Installation must be performed by a licensed electrician in accordance with AS/NZS 3000 wiring rules and local regulations.
Applications
- Commercial and industrial electrical distribution systems
- Main and sub-main switchboards
- Protection of electrical circuits against overloads and short circuits
- Suitable for use in large buildings, factories, and infrastructure projects
Standards & Compliance
- Complies with AS/NZS 60947.2 – Low-voltage switchgear and controlgear – Circuit-breakers
Environmental Benefits
- Enhances electrical safety, reducing risk of fire and equipment damage
- Long operational life reduces replacement frequency and waste
- Supports energy-efficient electrical distribution
Warranty Information
12 months manufacturer's warranty against defects.
Available Now
The Clipsal BTS NSX250H TM250D 4P/4P 240VA Circuit Breaker (SCHBLV431680/31680) is available for immediate purchase. Ideal for commercial and industrial electrical distribution applications.
