Orange Circular Power Cable 0.6/1kV 2C+E 2.5mm | LSZH Insulation | Blue Sheath | Per 10m by Eltech
Orange circular power cable with 0.6/1kV voltage rating and 2.5mm² conductor size—ideal for safe power distribution in residential and commercial settings. Built for reliable performance, featuring low smoke zero halogen (LSZH) insulation for enhanced fire safety.
Please sign in so that we can notify you about a reply
Sign in
Please login to continue to your account.
Product Name/Title: Orange Circular Power Cable 0.6/1kV 2C+E 2.5mm – Blue – LSZH
Brand: Eltech
SKU: ELT2025E.2-ENV
Alternatively Known As: 2 Core Plus Earth Power Cable, LSZH Power Cable, 0.6/1kV Power Cable, Blue Power Cable 2.5mm
Technical Specifications
- Voltage Rating: 0.6/1kV
- Conductor Size: 2.5mm²
- Cores: 2C+E (2 cores plus earth)
- Sheath Colour: Blue
- Drum Length: 500m
- Minimum Order Quantity: 10m increments
- Insulation Type: Low Smoke Zero Halogen (LSZH)
- Dimensions (H x L x W): 10mm x 500000mm x 10mm
- Weight: 0.15 kg
Key Features
- Low Smoke Zero Halogen (LSZH) insulation for enhanced fire safety
- Rated voltage: 0.6/1kV suitable for medium voltage power applications
- 2 cores plus earth (2C+E) configuration for reliable power and grounding
- Blue outer sheath for easy identification
- Available in 10m increments with 500m drum length
Professional Installation Requirements
- Installation should be performed by a licensed electrician to ensure compliance with electrical safety standards and regulations.
Applications
- Power distribution in residential, commercial, and industrial buildings
- Electrical installations requiring low smoke zero halogen cables
- Indoor and outdoor electrical wiring where safety and fire resistance are critical
Standards & Compliance
- Complies with AS/NZS 3000 – Wiring Rules (Electrical Installation)
Environmental Benefits
- Low Smoke Zero Halogen (LSZH) material reduces toxic emissions and smoke in case of fire, improving safety and environmental impact
Warranty Information
Standard manufacturer warranty applies. Please refer to Eltech warranty terms for details.
Available Now
The Eltech Orange Circular Power Cable 0.6/1kV 2C+E 2.5mm Blue LSZH is available now for immediate purchase. Ideal for safe and reliable power installations in residential, commercial, and industrial settings.
